The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.

An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Technical Data

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with all rele-
vant provisions of the directives 2011/65/EU, until
19 April 2016: 2004/108/EC, from 20 April 2016 on:
2014/30/EU, 2006/42/EC including their amendments and
complies with the following standards: EN 60745-1,
EN 60745-2-3, EN 50581.

Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
70764 Leinfelden-Echterdingen, GERMANY

Robert Bosch GmbH, Power Tools Division
70764 Leinfelden-Echterdingen, GERMANY
Leinfelden, 01.12.2015

Assembly



Before any work on the machine itself, pull the mains
plug.

Mounting the Protective Devices



Adjust protection guards in such a manner that spark-
ing toward the operator is prevented.

Protection Guard for Grinding (GGS 8 SH) (see figure A)

Place the protection guard

2

 on the spindle collar. Adapt the

position of the protection guard

2

 to the requirements of the

work step. Lock the protection guard

2

 with locking screw

13

and tighten the locking screw with at least 10 Nm.

Protection Guard for Grinding (GGS 8 H) (see figure E)

Place the protection guard

10

 on the spindle collar. Adapt the

position of the protection guard

10

 to the requirements of the

work step. Lock the protection guard

10

 with the two locking

nuts

18

 and tighten the locking nuts with at least 10 Nm.

After mounting the grinding tool, shut the protection guard

10

and tighten both wing nuts.

Straight grinder

GGS 8 SH

Article number

3 601 B14 ...

Rated power input

W

1 200

Output power

W

700

Max. speed

min

-1

8 000

Thread of grinder spindle

M 14

Max. spindle length

mm

31

Tool holder

mm

20

Max. grinding disc thickness

mm

32

Grinding tool diameter, max.

mm

125

Weight according to EPTA-Procedure 01:2014

kg

4.4

Restarting Protection



Protection class

/

II

The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.

Starting cycles generate brief voltage drops. Interference with other equipment/machines may occur in case of unfavourable mains system conditions.
Malfunctions are not to be expected for system impedances below 0.36 ohm.

Henk Becker
Executive Vice President
Engineering

Helmut Heinzelmann
Head of Product Certification
PT/ETM9
