– 2

1 Electrodes
2 Suction support
3 Suction hose
4 Hose hook
5 Push handle lock (NT 50/1 only)
6 Crevice nozzle
7 Air outlet, working air
8 Suction head
9 Suction head lock
10 Recessed grip
11 Dirt receptacle
12 Steering roller
13 Handle (NT 50/1 only)
14 Air inlet, motor cooling air
15 Floor nozzle
16 Suction tube
17 Stop for tool box
18 Rubber sleeve, screwable
19 Fixing eyelet
20 Filter cover
21 Carrying handle
22 Suction force regulator (continuous)
23 Tool adapter (Ap Te L only)
24 Push handle (NT 50/1 only)
25 Button for filter shake off system
26 Rotating knob
27 Socket (Ap Te L only)
28 Floor nozzle holder
29 Drain hose (NT 50/1 only)
30 Holder for suction pipe
31 Cable hook (NT 50/1 only)
32 Bender
33 Power cord
34 Bender holder (NT 30/1, NT 40/1 only)
35 Filter frame
36 Flat fold filter (PES)
37 Filter dedusting
38 Nameplate



DANGER

–

When the outgoing air is carried back
into the room, a sufficient ventilation
rate L in the room must be ensured. To
comply with the required limit values the
carried back volume flow must be 50%
of the fresh air volume flow (room vol-
ume V

R

 x ventilation rate L

W

) at maxi-

mum. Without a specific ventilation sys-
tem the following applies: L

W

=1h

–1

.

–

Only persons trained in the use of the
machine and the handling of substanc-
es for which the machine is to be used
including training in the safe disposal of
the sucked-in material may use the ma-
chine.

–

This appliance contains harmful dust.
Evacuation and maintenance work, in-
cluding the disposal of the dust collec-
tion containers, may only be performed
by specialists who wear the appropriate
protective equipment.

–

Do not use the appliance without the
complete filtering system.

Device elements

Symbols on the machine

WARNING: This appliance contains harm-
ful dust. The emptying and maintenance,
including the removal of the dust bag, may
only be executed by trained personnel
wearing suitable protection equipment. Do
not switch on until the complete filter sys-
tem has been installed.

Flat fold filter (cellulose)
Order No.

6.904-367.0

Flat fold filter (PES)
Order No.

6.907-662.0

Flat fold filter (PTFE)
Order No.

6.907-455.0

Safety instructions

17

EN
