GB

61

Remember that the quantity of air necessary for combustion must
never be less than 2m

3

/h for each kW of power (see total power in

kW on the appliance data plate fig. 8 B

*

).

In all other cases, i.e. when there are other gas appliances in the
same room, or when natural direct ventilation is not possible and
natural indirect or forced ventilation must be installed, contact
a qualified specialist who will install and make the ventilation
system, scrupulously observing the regulations contained in the
standards in force.

The openings must be so positioned that there are no draughts of
air which cannot be tolerated by the occupants.

Moreover to eliminate combustion products, it is forbidden to use
flues already used by other appliances.

GAS CONNECTING

We recommend to check wether the appliance has been foreseen
for the kind of gas distributed.
The appliance must be connected to the gas piping in a
workmanlike way and in conformity with the regulations in force
which lay down the installation of a safety valve at the end of the
piping.
For butane and propane a pressure reducer conforming to the
standards in force may perform this task. The seal gaskets must
be in accordance with rules.
Once the gas appliance has been connected, check the
connection seal by means of soapy water.

WARNING:
Do not use flames to check any gas leakages.

The possible connections are:
1) by rigid pipe in iron or copper.
2)

by flexible tube in stainless steel with continuing wall,

with mechanical connection in accordance with rules

(see  fig. 11).

min. 180 cm.

min. 180 cm.

electrical fan

min. 100 cm

2

.

min. 100 cm

2

.

min. 180 cm.

min. 180 cm.

electrical fan

min. 100 cm

2

.

min. 100 cm

2

.

мин. 180 см.

мин. 180 см.

электрический

вентилятор

мин. 100 см

2

.

мин. 100 см

2

.

Fig. 8B
