5

Specifications

Specifications

Continued from previous page

Internal

Connectors

∙

1x 24-pin ATX main power connector

∙

1x 8-pin ATX 12V power connector

∙

1x 4-pin ATX 12V power connector

∙

4x SATA 6Gb/s connectors

∙

2x M.2 slots (M-Key)

∙

2x USB 3.2 Gen 1 5Gbps connectors (supports additional 4

USB 3.2 Gen 1 5Gbps ports)

∙

2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)

∙

1x 4-pin CPU fan connector

∙

1x 4-pin water-pump fan connector

∙

4x 4-pin system fan connectors

∙

1x Front panel audio connector

∙

2x System panel connectors

∙

1x Chassis Intrusion connector

∙

1xTPM module connector

∙

1x Clear CMOS jumper

∙

1x TBT connector (Supports RTD3)

LED Features

∙

1x 4-pin RGB LED connector

∙

1x 3-pin RAINBOW LED connector

∙

4x EZ Debug LED

I/O Controller

NUVOTON NCT6687 Controller Chip

Hardware

Monitor

∙

CPU/ System/ Chipset temperature detection

∙

CPU/ System/ Pump fan speed detection

∙

CPU/ System/ Pump fan speed control

Form Factor

∙

ATX Form Factor

∙

12 in. x 9.6 in. (30.5 cm x 24.4 cm)

BIOS Features

∙

1x 256 Mb flash

∙

UEFI AMI BIOS

∙

ACPI 6.4, SMBIOS 3.4

∙

Multi-language

Continued on next page
