Safety Information

Specifications

Specifications

CPU

∙

Supports 12th Gen Intel® Core™ Processors

∙

Processor socket LGA1700

* Please go to www.msi.com to get the newest support status

as new processors are released.

Chipset

Intel®

Z690 chipset

Memory

∙

4x DDR4 memory slots, support up to 128GB*

∙

Supports 2133/ 2666/ 3200 MHz (by JEDEC & POR)

∙

Max overclocking frequency:

▪

1DPC 1R Max speed up to 5000+ MHz

▪

1DPC 2R Max speed up to 4600+ MHz

▪

2DPC 1R Max speed up to 4400+ MHz

▪

2DPC 2R Max speed up to 4000+ MHz

∙

Supports Dual-Channel mode

∙

Supports non-ECC, un-buffered memory

∙

Supports Intel® Extreme Memory Profile (XMP)

*Please refer www.msi.com for more information on

compatible memory

Expansion Slots

∙

2x PCIe x16 slots

▪

PCI_E1 (From CPU)

▫

Support PCIe 5.0 x16

▪

PCI_E3 (From Z690 chipset)

▫

Support PCIe 3.0 x4

∙

3x PCIe 3.0 x1 slots (Fom Z690 chipset)

∙

1x M.2 slot with E key for Intel® Wireless-AX CNVi and PCIe

WiFi module

Onboard

Graphics

∙

1x HDMI 1.4 with HDR port, supports a maximum resolution

of 4K 30Hz *

/

**

∙

1x DisplayPort 1.4 port, supports a maximum resolution of

4K 60Hz *

/

**

* Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the CPU

installed.

Multi-GPU

∙

Supports AMD CrossFire™ Technology

Continued on next page
