Continued from previous column

Internal USB

Connectors

∙

1x USB 3.2 Gen 1 5Gbps Type-C connector (From B660

chipset)

∙

1x USB 3.2 Gen 1 5Gbps Type-A connector (From

ASM1074)
•  Supports additional 2 USB 3.2 Gen 1 5Gbps ports

∙

2x USB 2.0 Type-A connectors (From B660 chipset)
•  Supports additional 4 USB 2.0 ports

Fan Connectors

∙

1x 4-pin CPU fan connector

∙

1x 4-pin water-pump fan connector

∙

2x 4-pin system fan connectors

System Connectors

∙

1x Front panel audio connector

∙

2x System panel connectors

∙

1x Chassis Intrusion connector

∙

1x TPM module connector

∙

1x Tuning Controller connector

∙

1x TBT connector (supports RTD3)

∙

1x Serial port

Jumpers

∙

1x Clear CMOS jumper

LED Features

∙

1x 4-pin RGB LED connector

∙

2x 3-pin RAINBOW LED connectors

∙

4x EZ Debug LED

Back Panel

Connectors

∙

1x PS/2 mouse/ keyboard port

∙

2x USB 2.0 Type-A ports (From B660 chipset)

∙

2x DisplayPort ports

∙

2x HDMI ports

∙

2x USB 3.2 Gen 1 5Gbps Type-A ports (From B660 chipset)

∙

2x USB 3.2 Gen 2 10Gbps Type-A ports (From B660

chipset)

∙

1x 2.5G LAN (RJ45) port

∙

2x Wi-Fi Antenna connectors (PRO B660M-A WIFI)

∙

3x audio jacks

I/O Controller

NUVOTON NCT6687 Controller Chip

Continued on next column
