Appendix
The BIOS Setup menus described in this section may differ from the exact settings for your moth-
erboard. The actual BIOS Setup menu options you will see shall depend on the motherboard you
have and the BIOS version.
Figure 1
Step 2:
Save changes and exit BIOS Setup.
5-1-2 Configuring JMicron JMB362 SATA Controller
A. Installing SATA hard drive(s) in your computer
Attach one end of the SATA signal cable to the rear of the SATA hard drive and the other end to available
SATA port on the motherboard. The JMicron JMB362 SATA controller controls the onboard eSATA connectors
on the back panel. Then connect the power connector from your power supply to the hard drive.
B. Configuring SATA controller mode in BIOS Setup
Make sure to configure the SATA controller mode correctly in system BIOS Setup.
Step 1:
Turn on your computer and press <Delete> to enter BIOS Setup during the POST. In BIOS Setup, go to
Inte-
grated Peripherals
. To enable RAID, set
eSATA Controller
to
Enabled
and set
eSATA Ctrl Mode
to
RAID
.
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
Integrated Peripherals
eXtreme Hard Drive (XHD)
[Disabled]
ICH SATA Control Mode
[IDE]
SATA Port0-3 Native Mode
[Disabled]
USB Controllers
[Enabled]
USB Keyboard Function
[Enabled]
USB Mouse Function
[Disabled]
USB Storage Function
[Enabled]
Onboard Audio
[Enabled]
Onboard H/W LAN
[Enabled]
Onboard USB 3.0 Controller
[Enabled]
eSATA Controller
[Enabled]
eSATA Ctrl Mode
[RAID]
GSATA3 6_7/IDE Controller
[Enabled]
GSATA3 6_7/IDE Ctrl Mode
[IDE]
higf
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
