BIOS Setup
- 40 -
(Note) This item appears only when you install a memory module that supports this feature.
>>>>> Standard Clock Control
Base Clock(BCLK) Control
Enables or disables the control of CPU base clock.
Enabled
will allow the
BCLK Frequency(Mhz)
item
below to be configurable. Note: If your system fails to boot after overclocking, please wait for 20 seconds
to allow for automated system reboot, or clear the CMOS values to reset the board to default values.
(Default: Disabled)
BCLK Frequency(Mhz)
Allows you to manually set the CPU base clock. The adjustable range is from 100 MHz to 600 MHz. This
item is configurable only if the Base Clock(BCLK) Control option is enabled.
Important:
It is highly recommended that the CPU frequency be set in accordance with the CPU
specifications.
Extreme Memory Profile (X.M.P.)
(Note)
Allows the BIOS to read the SPD data on XMP memory module(s) to enhance memory performance
when enabled.
Disabled
Disables this function. (Default)
Profile1
Uses Profile 1 settings.
Profile2
(Note)
Uses Profile 2 settings.
System Memory Multiplier (SPD)
Allows you to set the system memory multiplier.
Auto
sets memory multiplier according to memory SPD
data. (Default: Auto)
Memory Frequency(Mhz)
The first memory frequency value is the normal operating frequency of the memory being used; the
second is the memory frequency that is automatically adjusted according to the
BCLK Frequency(Mhz)
and
System Memory Multiplier
settings.
PCI Express Frequency(Mhz)
Allows you to manually set the PCIe clock frequency. The adjustable range is from 90 MHz to 150 MHz.
Auto
sets the PCIe clock frequency to standard 100 MHz. (Default: Auto)
>>>>> Advanced Clock Control
CPU Clock Drive
Allows you to adjust the amplitude of the CPU and Chipset clock.
Options are: 700mV, 800mV (default), 900mV, 1000mV.
PCI Express Clock Drive
Allows you to adjust the amplitude of the PCI Express and Chipset clock.
Options are: 700mV, 800mV, 900mV (default), 1000mV.
CPU Clock Skew
Allows you to set the CPU clock prior to the Chipset clock.
Options are: 0ps~750ps. (Default: 0ps)
IOH Clock Skew
Allows you to set the North Bridge clock prior to the CPU clock.
Options are: 0ps~750ps. (Default: 0ps)
