24

GB

Common connection

When the positions of the red and
yellow leads are inverted

When the car without ACC position

After matching the connections and
switching power supply leads correctly,
connect the unit to the car’s power supply. If
you have any questions and problems
connecting your unit that are not covered in
this manual, consult the car dealer.

1

To enable the wired remote control,
set [STR CONTROL] in [SET STEERING]
to [PRESET] (page 10).

Installation

Before installing the unit, remove the
protection collar



 and the bracket



 from

the unit.

1

Pinch both edges of the protection
collar



, then pull it out.

2

Insert both release keys



 until they

click, and pull down the bracket



,

then pull up the unit to separate.

12

continuous power
supply

Yellow

15 switched power supply

Red

12 switched power supply

Yellow

15

continuous power
supply

Red

Using the wired remote control

Red

Red

Yellow

Yellow

Red

Red

Yellow

Yellow

Red

Red

Yellow

Yellow

Removing the protection collar
and the bracket









Face the hook inwards.
