10000 ft² (930m²)

Zoom function for E30Zx

Zoom in
Press and hold the zoom in button to increase the
optical zoom. When increasing to 30X optical zoom,
if presses the zoom in button again, the camera
begins to increase digital zoom. The digital zoom
can increase to 6X at the most.

Zoom out
Press and hold the zoom out button to decrease the
optical zoom. When decreasing to 1X digital zoom, if
presses the zoom out button again, the camera
begins to decrease optical zoom.

One Key to 1x Image
Tap the [         ] on the screen you can return the
camera to 1X zoom

Notice:

 For more detailed introduction please refer

to the corresponding Gimbal User Manual.

Per-Flight Preparation

Environment Requirements
Always operate the Drone in open areas (approxi-
mately 10 0 0 0 square feet/930 square meters or
more) that are free from people, vehicles, trees and
other obstructions. Never fly near or above crowds,
airports or buildings.

Never attempt to operate the drone near tall build-
ings/obstructions that do not offer a clear view of
the sky (a minimum clearance of 100°).

11

ZOOM IN

ZOOM OUT

Other payloads
Yuneec has several different camera/payload devices for use on the H520E/H520E-RTK.
Get more information on

www.yuneec.com

.

SD CARD SELECTION
Yuneec recommend using a SDXC Class 10 UHS-3 micro SD card for recording 4k video. Using the
UHS-3 card allows the camera buffer to record to the micro SD card faster resulting in fewer buffers
overrun.
