Visible light Camera

E90X

Yuneec’ s E90X camera is a one-inch CMOS sensor
to capture high quality images with 4k 10 bit in
camera color processing. Images may be captured
in formats of JPEG or DNG format, or simultaneous
capture of both formats. Video may be recorded in
UHD, 2K, or HD resolutions at a variety of frame
rates.
When the Gimbal was connected successfully the
gimbal type will be shown correctly on the screen.

Tap the Camera Setting Button to set more photo-
graphic parameters.

Notice:

For more detailed introduction please refer

to the corresponding Gimbal User Manual.

Thermal imaging camera

ETx/E10Tx/E10Tvx

This series are innovative combination of 3-axis gimbals, thermal imaging camera and low-light camera.
While the thermal imaging camera selectively measures the temperature in the image enabling it to dis-
play relative temperature differences, the low-light RGB camera has a 20 times higher sensitivity than the
human eye and can still take excellent shots even in low light conditions. Both images are streamed live on
the remote control at the same time, and can be viewed separately as a picture-in-picture or as an overlay.
As same as the E90x gimbal, When the Gimbal was connected successfully the gimbal type will be shown
correctly on the screen, also tap the Camera Setting Button to set more photographic parameters both for
thermal imaging and visible light camera.

Notice:

For more detailed introduction please refer to the corresponding Gimbal User Manual.

Variable-focus camera

E30Zx

The E30Zx is a powerful 30x zoom drone camera and makes it easy to zoom in on distant objects to gain
valuable details. The compact camera housing contains a 1/2.8" CMOS sensor, which provides high-quality
and stabilized recordings even in low light conditions. In addition to the 30x optical zoom, the camera
offers a 6x digital zoom for flexible application options such as inspection, search and rescue operations,
monitoring, people search, and much more.
As same as the E90x gimbal, When the Gimbal was connected successfully the gimbal type will be shown
correctly on the screen, also tap the Camera Setting Button to set more photographic parameters.
