7

en

Overview

(see Figs.

A

,

B

,

C

,

D

 and

E

 at the start of

the instructions)

1

  Bean container

  2

  Aroma cover

3

  Selector for grind setting

  4

  Drawer

    (ground coffee / cleaning tablet)

5

  Brewing unit (

Figure

E

)

a)

 Brewing unit

b)

 Door

c)

  Pushbutton

d)

 Lock

6

  Milk frother (

Figure

C

)

removable

a)

 Steam valve

b)

 Metal sleeve

c)

 Frothing tube

d)

 Steam nozzle

e)

Air hole

7

  Height-adjustable coffee outlet

8

  Drip tray (

Figure

D

)

a)

 Panel

b)

 Coffee grounds container

c)

 Drip tray for coffee outlet

d)

 Grate for coffee outlet

e)

 Float

9

  Power on/off switch

O / I

10

  Start button

C

11

  Steam button

B

12

  Service button

A

13

  “Coffee strength” rotary knob

14

  “Drink selection” rotary knob

15

  LED display

16

  Removable water tank

17

  Water tank lid

 18

   Measuring spoon

(insertion aid for water filter)

19

   Storage compartment for

measuring spoon

20

  Power cable with storage compartment

¡

¡

Risk of scalding

The milk frother outlet (6) gets very hot.

After use, allow to cool down first before

touching.

Use this appliance only after the milk frother

(6) has been fully assembled and installed.

¡

¡

Risk of suffocation

Do not allow children to play with packaging

material.

Included in delivery

(see overview image at the start of the

instructions)

1

    TE501 fully automatic

espresso machine

2

   Operating instructions

3

   Water hardness testing strips

4

   Measuring spoon

5

   Grease (tube)
