12

11-1 ENGINE AIR CLEANER

CAUTION:

Do not allow dirt or dust to clog the air

filter foam element.

The engine air cleaner element must be serviced
(cleaned) after 25 hours normal mowing. The foam
element must be serviced regularly if the mower is used in
dry dusty conditions. (refer to ENGINE OWNER’S
MANUAL)

To CLEAN AIR FILTER (Fig. 25)

1. Remove screw.
2. Remove cover.
3. Wash filter element in soap water.

DO NOT USE

GASOLINE!

4. Air dry filter element.
5. Place a few drops of SAE30 oil on the foam filter and

squeeze tightly to remove any excess oil.

6. Reinstall filter.

NOTE:

Replace filter if frayed, torn, damaged or

unable to be cleaned.

11-2 CUTTING BLADE

CAUTION:

Be sure to disconnect and ground the

spark plug wire before working on the cutting blade to
prevent accidental engine starting. Protect hands by using
heavy gloves or a rag to grasp the cutting blades.
Tip mower as specified in separate engine manual.
Remove the hex bolt and washer which hold the blade
and blade adapter to the engine crankshaft. Remove the
blade and adapter from the crankshaft.

WARNING:

Periodically inspect the blade

adapter for cracks, especially if you strike a foreign object.
Replace when necessary.
For best results your blade should be sharp. The blade
may be resharpened by removing it and either grinding or
filing the cutting edge keeping as close to the original
bevel as possible. It is extremely important that each
cutting edge receives an equal amount of grinding to
prevent an unbalanced blade. Improper blade balance will
result in excessive vibration causing eventual damage to
the engine and mower. Be sure to carefully balance blade
after sharpening. The blade can be tested for balance by
balancing it on a round shaft screwdriver. Remove metal
from the heavy side until it balances evenly.

(Fig. 26)

Before reassembling the blade and the blade adapter to
the unit, lubricate the engine crankshaft and the inner
surface of the blade adapter with light oil. Install the blade
adapter on the crankshaft with the “star” away from the
engine. Refer to

Fig. 26

. Place the blade with the part

number facing away from the adapter. Align the washer
over the blade and insert the hex bolt. Tighten the hex bolt
to the torque listed below.

11-3 BLADE MOUNTING TORQUE

Center Bolt must be tightened to 40 – 54 Nm torque. To
insure safe operation of your unit. ALL nuts and bolts
must be checked periodically for correct tightness. After
prolonged use, especially in sandy soil conditions, the
blade will become worn and lose some of the original
shape. Cutting efficiency will be reduced and the blade
should be replaced.
Replace with an approved factory replacement blade only.
Possible damage resulting from blade unbalance
condition is not the responsibility of the manufacturer.
When you change the blade, must use the original type
marked on the blade (MAKITA 263001554) (for order the
blade, pls. contact your local dealer or call our company).

WARNING:

Do not touch rotating blade.

11-4 ENGINE

Refer to the separate engine manual for engine
maintenance instructions.
Maintain engine oil as instructed in the separate engine
manual packed with your unit.
Read and follow instructions carefully.
Service air cleaner as per separate engine manual under
normal conditions. Clean every few hours under
extremely dusty conditions. Poor engine performance and
flooding usually indicates that the air cleaner should be
serviced.
To service the air cleaner, refer to the separate engine
manual packed with your unit.
The spark plug should be cleaned and the gap reset once
a season. Spark plug replacement is recommended at the
start of each mowing season; check engine manual for
correct plug type and gap specifications.
Clean the engine regularly with a cloth or brush. Keep the
cooling system (blower housing area) clean to permit
proper air circulation which is essential to engine
performance and life. Be certain to remove all grass, dirt
and combustible debris from muffler area.

12. STORAGE INSTRUCTIONS

(OFF SEASON)

The following steps should be taken to prepare lawn
mower for storage.
1. Empty the tank after the last mowing of the season.
a) Empty the petrol tank with a suction pump.

CAUTION:

 Do not drain the petrol in closed

rooms, close proximity of open fire, etc. Do not smoke!
Petrol fumes can cause explosion or fire.
b) Start the engine and let it run until it has used up all

remaining petrol and stalls.

c) Remove the spark plug. Use an oilcan to fill approx.

20 ml oil into the combustion chamber. Operate the
starter to evenly distribute the oil in the combustion
chamber. Replace the spark plug.

2. Clean and grease the lawnmower carefully as

described above under “Lubrication”.

3. Slightly grease the cutter to avoid corrosion.
4. Store the lawnmower in a dry, clean and frost-

protected place, out of reach of unauthorized persons.
