•  Warning:

if the bulbs are not working, ensure that they are

screwed in fully.

•

Installation:

Prior to proceeding with the assembly operations (according

to the model that you have purchased), to facilitate handling

of the device, remove the grille as indicated in figure 8 or the

aluminium panels as indicated in figure 9.

•

The flange

D

, to which the air exhaust pipe is connected,

and a plug

B

, used to shut off the unused air outlet, are both

supplied with the product.

•

This device may be installed in two different ways:

1. Fixing  the  hood  to  the  lower  part  of  the  wall  cabinet

(Fig.2):

- Make 4 holes in the wall cabinet respecting the measurements

indicated in figures 2A-2C.

- Position the hood underneath the wall cabinet and fix it into

place using 4 screws (not supplied) suitable for the type of

cabinet.

2. Fixing the hood to the wall (Fig.2):

- Make 4 holes in the wall cabinet respecting the measurements

indicated in figures 2A-2B.

- Hang the hood on the wall, using the 2 holes

H

, align it in a

horizontal position and fix it definitively to the wall using the

two lower safety holes

I

(Fig.2B).

- For the various installations use screws and screw anchors

suited to the type of wall (e.g. reinforced concrete, plaster-

board, etc.). If the screws and screw anchors are provided with

the product, check that they are suitable for the type of wall

on which the hood is to be fixed.

•

Mounting decorative ducts (optional):

- This hood model may have decorative ducts as optional ac-

cessories - ask your retailer for information.

- Provide the electrical power supply within the space of the

decorative duct.

- If your appliance must be installed as an extractor version or

as a version with an external motor, make sure an air exhaust

hole is prepared (Fig.1B - Fig.1C).

- Adjust the width of the upper duct support bracket (Fig.4).

Then fix it to the wall so that it is on the same axis as the hood

using screws

A

 (Fig.4) and adhering to the distance from the

ceiling shown in (Fig.2B). Connect the flexible hose (not sup-

plied) to the flange

D

 (Fig.1B).

- Put the upper connector

F

into the lower connector

G

 and

hang the decorative ducts on the wall, as indicated in figure 5.

- Connect the flexible hose to the air exhaust hole made previ-

ously (only in the extraction or external motor version).

- Pull out the top connector

F

as far as the bracket and fix it

using screws

C

 (Fig.4).

- When carrying out the fixing procedures, use only screws

and screw anchors which are suited to the type of wall (e.g.

reinforced concrete, plasterboard etc.).

- If the screws and screw anchors are supplied with the ap-

pliance, make sure that they are suited to the type of wall to

which the hood must be fixed.

•

The hood is already prepared for the version with which it

was ordered. The versions may be:

- Extraction

 (Fig.1B-6).

- Filter

 (Fig.1A-7-11).

- If the hood is an

extractor

 model, the lever

C

 must be posi-

tioned as indicated in figure 6.

- If the hood is a

filter

 model, the lever

C

 must be positioned

as indicated in figure 7.

•  Extractor version:

The appliance expels the fumes through an outside wall or

a duct. It is necessary to buy a telescopic pipe in accordance

with the standards in use (inflammable) and connect it to

flange

D

 (Fig.1B). The flange

D

 is supplied with the product

and should be fixed above the air outlet hole of the hood as

indicated in figure 6.

•  Filtering version:

To transform an extractor hood version into a filter hood ver-

sion, contact your appliance dealer and ask for active charcoal

filters. The filters should be fitted to the extraction assembly

inside the hood, by centring them and rotating them 90

degrees, until they click into place (Fig.11). To do this, remove

the grille

D

 or the panels

G

 (Fig.8 - Fig.9). Close the air outlet

opening with the plug

B

, as indicated in figure 7.

 USE AND MAINTENANCE

•

We recommend that the cooker hood is switched on before

any food is cooked. We also recommend that the appliance is

left running for 15 minutes after the food is cooked, in order

to thoroughly eliminate all contaminated air. The effective

performance of the cooker hood depends on constant main-

tenance; the anti-grease filter and the active carbon filter both

require special attention.

•  The  anti-grease  filter

 is responsible retaining the grease

particles suspended in the air, therefore it is subject to clogging

with variable frequency according to the use of the appliance.

-  To prevent the danger of possible fires, at least every 2

months one must wash the anti-grease filters by hand using

non-abrasive neutral liquid detergents or in the dishwasher

at low temperatures and on short cycles.

-  In the event that acrylic anti-grease filters are used, hand-

wash every 2 months, using neutral non-abrasive liquid

detergents and replace them after every 6 washes.

-  After a few washes, colour alterations may occur. This does

not give the right to claim their replacement.

•  The  active  carbon  filters

 are used to purify the air that is

sent back into the room and its function is to mitigate the

unpleasant odours produced by cooking.

-  The non-regenerable active carbon filters must be replaced

at least every 4 months. The saturation of the active charcoal

depends on the more or less prolonged use of the appliance,

on the type of kitchen and on the frequency with which anti-

grease filter is cleaned.

•  Before remounting the anti-grease filters and the regen

-

erable active charcoal filters it is important that they are

completely dry.

•  Clean the hood frequently, both internally and externally,

using a cloth dampened with denatured alcohol or neutral

liquid detergents that are non abrasive.

•

The lighting .system is designed for use during cooking

and not for the prolonged general lighting of the room. The

prolonged use of the lighting system significantly decreases

the average duration of the bulbs.

•  Attention:

 the non compliance with the hood cleaning

warnings and with the replacement and cleaning of the filters

entails risk of fires. One therefore recommends keeping to the

suggested instructions.

•  Replacing the aluminium panels:

To replace the aluminium panels, simply pull handle

A

 as

shown in Fig.9.
