7

EN

English

II.

TECHNICAL PARAMETERS

1.

Nominal volume, litres - see the appliance’s rating plate

2.

Nominal voltage - see the appliance’s rating plate

3.

Nominal power consumption - see the appliance’s rating plate

4.

Nominal pressure - see the appliance’s rating plate

This is not the water mains pressure. This is the pressure that is declared for the

appliance and refers to the requirements of the safety standards.

5.

Water heater type – closed type accumulating water heater, with thermal

insulation

6.

Daily energy consumption – see Annex I

7.

Rated load profile – see Annex I

8.

Quantity of mixed water at 40°C V40 in litres – see Annex I

9.

Maximum temperature of the thermostat – see Annex I

10.

Default temperature settings – see Annex I

11.

Energy efficiency during water heating – see Annex I

III.

DESCRIPTION AND PRINCIPLE OF OPERATION

The appliance consists of a body, flange at the bottom side (for water heaters

intended for vertical mounting) or at the sides (for water heaters intended for

horizontal mounting), protective plastic panel and a safety-return valve.

1.

The housing consists of two steel tanks (water tanks) and a casing (outer

shell) with heat insulation between them from an environmentally clean high-

density polyurethane foam and a housing (outer shell) with thermal insulation

placed in-between made of ecologically clean high density polyurethane, and

two pipes with thread G½‘’ for cold water supply (marked by a blue ring) and hot

water outlet pipe (marked by a red ring).

The inner tanks are made of steel protected from corrosion by a special glass-

ceramic or enamel coating.

2.

An electric heater and a magnesium protector are installed on each flange.

The electric heater is used for heating the water in the tank and is operated

by the thermostat, which automatically maintains the set temperature. The

appliance has two built-in devices (for each of the water tanks) for overheat

protection (thermo-switches) which switch off the respective heater from the

mains when the water temperature raises too much.

3.

The safety-return valve prevents the appliance’s complete emptying if the

cold water supply stops from the water mains. The valve protects the appliance

from pressure increases higher than the allowed value during heating mode

(an increase of temperature causes water expansion and therefore pressure

increase) by releasing the excess pressure through the drainage opening.

The safety-return valve cannot protect the appliance in the event of water mains

pressure that is higher than the pressure stated for the appliance.

IV.

MOUNTING AND SWITCHING ON

Attention! Improper installation and connection of the appliance will make it

hazardous with grave health consequences and may cause even death of users.

It may also damage their property, that of third parties, as a result of flooding,

explosion, fire

. Installation, connection to the water mains and connection to power

lines must be carried out by qualified technicians. A qualified technician means a person

who has appropriate competencies pursuant to the regulations of the relevant state.

1.

Mounting

We recommend the device to be mounted in close proximity to locations where hot

water is used in order to reduce heat losses during transportation in the pipelines.

If the device is mounted in a bathroom, it should be in such a place so as not to be

poured with water from the showerhead or a portable showerhead attachment.
When mounted on a wall - the device is suspended by means of the M8 bolts attached

to the housing, which are installed on brackets pre-mounted and levelled with the

wall. The load-bearing brackets and dowels for wall mounting are included in the kit.
Vertical installation scheme - Fig. 4.1

Horizontal installation scheme – Fig. 4 2.
Depending on the installation method of the appliances (horizontal or vertical), you

can orient the TESY logo on the control panel according to the orientation of the

appliances. - Fig. 4 2.

In order to prevent injury to the user and/or third persons in the event of faults in

the system for hot water supply, the appliance must be installed in premises

with floor hydro insulation and drainage to the sewerage. Under no circumstances

should you place objects which are not waterproof under the appliance. If the

appliance is installed in premises without floor hydro insulation, a protective tub with

drainage to the sewerage must be in place under the appliance.

Note:

 The set does not include a protective tub and it should be chosen/

purchased by the user.

2.

Connecting the water heater to the water supply system

Fig. 5   Where: 1 - Inlet pipe; 2 - safety valve; 3 - reducing valve (for pressure in

the water mains higher than 0.6 MPa); 4 - stop valve; 5 - funnel connected to the

sewerage; 6 – hose; 7 – drain water tap.

Upon connecting the water heater to the water mains you must consider the

indicative colour markings (rings) affixed to the pipes: blue for cold (incoming)

water, red for hot (outgoing) water.

The mounting of the safety return-valve supplied with the water heater is

obligatory. The safety return-valve must be mounted on the cold water supply

pipe, in accordance with the direction of the arrow stamped on its body, indicating the

direction of the incoming water.

Exception:

 If the local regulations (norms) require the use of another protection

valve or device (which conforms to EN 1487 or EN 1489), then it must be

purchased additionally. For device operating in accordance with EN 1487 the declared

maximum operational pressure must be no more than 0.7 MPa. For other protection

valves, the pressure at which they are calibrated must be 0.1 MPa lower than the one

marked on the appliance’s plate. In these cases the safety valve which the appliance is

supplied with should not be used.

Other type of stopping armature is not allowed between the protection return

valve (the protective device) and the appliance.

The presence of other (old) safety return-valves may lead to a breakdown of

your appliance and they must be removed.

The attaching of the safety return-valve to threads longer than 10 mm is not

allowed; otherwise this may damage the valve and therefore pose danger to

your appliance.

The safety-return valve and the pipe between the valve and the water heater

must be protected from freezing. In case of hose draining its free end must be

always open to the atmosphere (not to be immersed). Make sure that the hose is also

protected from freezing.

To fill the water heater with water first open the hot-water tap of the water-mixing

faucet.  Then open the cold-water tap of the water-mixing faucet. The appliance is full

when a constant stream of water flows from the water-mixing faucet. Then close the

hot water tap.

When you have to empty the water heater, first you must cut off its power supply.

Then stop feeding water to the appliance. Open the hot-water tap of the water-

mixing faucet. Open tap 7 (fig. 5) in order to drain the water from water tank. If there

is no such tap built in the pipeline, than the water can be drained directly from the inlet

pipe of the water tank, having it disconnected from the water mains prior to this
When removing the flange, it is normal for several litres of water, which have remained

in the water tank, to be discharged.

Measures must be taken to prevent damages by the discharged water.

If the pressure in the water mains piping exceeds the value specified in paragraph II

above, a pressure-reducing valve must be installed, otherwise the water heater will

not be correctly operated. The manufacturer will not bear any liability for problems

arising from improper operation of the appliance.

3.

Connecting the water heater to the electrical mains

Make sure the appliance is full of water before switching on the electrical power

supply.

3.1.

For models with a power cord with a plug, connection to the electrical mains is

done by inserting the plug into an electrical socket.
Disconnection from the electrical mains is done by unplugging the power cord from

the socket.

The electrical socket must be properly connected to a separate current loop that

is provided with a safety fuse. It must be earthed.

3.2.

Water heaters without power cord

The appliance has to be connected to a separate current loop of the stationary

electrical installation, provided with a safety fuse with nominal current of 16A

(20A for power > 3700W). Connection is done using copper single core (rigid)

conductors – cable 3 x 2.5 mm² for a total power of 3000W (cable 3 x 4.0 mm² for

power > 3700W).
In the electrical circuit providing power supply for the appliance there has

to an inbuilt device which would disconnect all poles in case of category III

overvoltage.
To install the power supply wire to the water heater, remove the plastic cover

(Fig.7.2).
Connect the power supply wire in compliance with the marking on the terminals,

as it follows:

 •

the phase – to marking A or A1, L or L1;

 •

the neutral – to marking N (B or B1 or N1);

 •

The safety wire must be connected to the screw joint marked with  .

After installation, put the plastic cover back in its place!

Explanations to Fig. 6:

T1, T2 - thermal circuit breaker; TR/EC - thermal regulator/ electronic control; R1,

R2 – heating element; F1, F2 - flange; S1, S2 - sensor.

V.

ANTI-CORROSION PROTECTION – MAGNESIUM ANODE

The magnesium anode provides additional protection to the water tank’s inner

surface from corrosion. It is an element undergoing wear and tear and is subject

to periodic replacement, which is at the expense of the user. In view of the long-

term and accident-free use of your water heater, the manufacturer recommends

periodic inspections of the magnesium anode's condition by a qualified technician

and replacement whenever required, and this could be performed during the

appliance's technical preventive maintenance.

For replacements, please contact the authorized service centres or a qualified

technician!
