SX 50 / SX 80 / SX 100 / SX 120

5. Initial operation

22

Double Power

Depending on the home installation, the following connection variations are possible:
•  Variant A, (fig. 12.2)

If no low-tariff electricity is to be used, do not remove bridge between L1 and L1T.

•  Variant B, (fig. 13)

Connect the output of the autotimer (delivered by the electricity provider) with L1 and L1T.

•  Variant C, (fig. 14)

Connect switched phase L1T (connection for low-tariff power) to L1T terminal.

•  Variant D, (fig. 15)

Connect switched phase L1 to terminal L1 and L1T.

Refer to the connection types recommended for double power (page VI fig. 12.2)

According to the duration of the off-peak period of either 8 or 4 hours, and the associated loads

(refer to connection types on page VI), set the power switch “S1” to the correct positions, 5 /6 / 7,

of the double power set-up.

Single Power

Depending on the home installation, the following connection variations are possible:
Refer to the connection types recommended for single power (page V fig 12.1)

Set power switch “S1” on the electronic board to positions 1 / 2 / 3 / 4 “single power”.

Boiler

Depending on the home installation, the following connection variations are possible: Refer to the connection types

recommended for boiler switch (page V fig. 12.1) Set power switch “S1” on the electronic board to positions 8 / 9 / 0

“Boiler mode”.
Finally, separate the appropriate circuit fig. (E1/E2/E3/E4) and the corresponding power-switch position “S1” from the

enclosed adhesive foil and adhere to the pad provided. Fill out the information decal about the installed circuit and

installed load and adhere to the outside of the cover.

Initial Use

1.  Fill the reservoir and flush it out until water discharges from all hot water taps bubble free, otherwise the tempera-

ture sensor and retainer will be damaged and require replacing.

2.  Check all water connections for leaking water.
3.  Switch on the power supply to the appliance.
4.  Press the “ON/OFF”-button (fig. 1; ref. A).
5.  During heating, displaced water must drop from the discharge of the safety valve (closed operation) or out of the

mixer tap (open operation). Monitor the first heating cycle.

Temperature Limit (fig. 11)

Set the temperature limiter (40/60 or 85 °C) by the selector on PCB board. The appliance is factory-set at the position

85 °C.

Danger of electric shock!

The power switch “S1” may only be operated in an unpowered condition!!
