13

INSTRUCTION MANUAL

step 2    Place the pulse transmitter just below your chest and guide

the elastic strap over your back to the other end of the pulse
transmitter

step 3    Connect the second end of the plastic strap to the pulse

transmitter

step 4    Use the size adjustment of the elastic strap to adjust the chest

belt to your chest size

Please note:
-  Do not adjust the chest belt too loose; if it is too loose it can slip if

there are jolts (e.g. when walking)

-  When putting on the chest belt moisten the electrodes so that trouble-

free function is also ensured when starting exercise, before contact is
established through sweat.

-  Range of the pulse-chest belt transmitter = 0.90 m

2.4. MOUNTING THE COMPUTER ON THE WRIST BAND

>>> P09

step 1   Insert the computer into the opened wrist band
step 2    Insert the lock into the wrist band holder from below
step 3    Turn the lock with a coin to tighten it

ATTENTION: Never use a screwdriver to operate the lock. This could
damage the lock (if the lock should be damaged then you can get the
lock as original replacement part)

3. INITIAL OPERATION

3.1. INITIAL OPERATION, AC-BUTTON

>>> P09-2

After inserting the batteries we recommend that you

fi

rst reset the de-

vice to factory settings to ensure that no residual data from the quality
control process remains in the computer. This puts the computer into
an assured start mode.
-  Press the AC button for approximately 2 seconds with a sharp object,

such as a pencil

3.2. LANGUAGE SELECTION
3sec.

ç

Setting mode LANGUAGE SELECT

step 2

‚

Con

fi

rm LANGUAGE SELECT with M

step 3

∂

  ƒ

 Press the up or down button until the desired langu-
age appears

step 4

‚

Con

fi

rm your language selection with M

3.3. MANUAL PAIRING - INITIAL OPERATION WIRELESS SYSTEM
For initial operation of the digital wireless system manual pairing must
ALWAYS be executed. Manual pairing ensures that the computer learns
the coding of the transmitter you are using.
step 1   Insert the computer into the twist-click holder
step 2    Ensure that there are no ANT+Sport digital transmitters other

than the transmitter you are using within a 5-meter area
around the computer

Your computer will randomly select one of 128,000 codes. This ensures
that signals of other transmitters are not received or processed (e.g.
when riding in a group). If dashes are shown in the display, in spite
of pairing, you must repeat the manual pairing process. In doing so
ensure that the electrodes of the pulse transmitter belt are wet, or that
the distance between the magnets and the speed/cadence transmitter
is not greater than 5 mm.
