9

english

Technical passporT

Mixed and gas fuelled built-in hot plates

COMPL Y WITH THE

DIMENSIONS (mm)

Product

A

B

С

D

E

FV3X6

F3E6

FV3XW

FV3EW

FV3XE

FV3EG

280

480

57.5

57.5

min

100

FV3VR

FM3VR

285

485

60

60

min

60

 IMPORTANT  INSTALLATION
SPECIFICATIONS

The installer should note that the

appliance that side walls should be
no higher than the hot plate itself.
Furthermore, the rear wall, the surfaces
surrounding and adjacent to the
appliance must be able to withstand an
overtemperature of 65 K.

The adhesive used to stick the

plastic laminate to the cabinet must be
able to withstand a temperature of not
less than 150° C otherwise the laminate
could come unstuck.

The appliance must be installed in

compliance with the provisions in force.

This appliance is not connected to a

device able to dispose of the combustion
fumes. It must therefore be connected in
compliance with the above mentioned
installation standards. Particular
care should be paid to the following
provisions governing ventilation and
aeration.

6) ROOM VENTILATION
(for gas product)

It is essential to ensure that the

room in which the appliance is installed
is permanently ventilated in order to
allow the appliance itself to operate
correctly. The necessary amount of air is
that required lor regular gas combustion
and ventilation of the relative room, the
volume of which must not be less than
20 m

3

.  Air  must  naturally  fl ow  through

permanent openings in the walls of the
room in question. These openings must
vent the fumes outdoors and their section
must be at least 100 cm

2

 Construction

of the openings must ensure that the
openings themselves may never be
blocked. Indirect ventilation by air drawn
from an adjacent room is also permitted,
in strict compliance with the provisions
in force.

7) LOCATION AND AERATION

Gas cooking appliances must

always dispose of their combustion
fumes through hoods. These must be
connected to fl ues, chimneys or straight
outside. lf it is not possible to install a
hood, an electric fan can be installed on
a window or on a wall facing outside.
This must be activated at the same
time as the appliance, so long as the
specifi cations in the provisions in force
are strictly complied with.
