31

English (Original instructions)

Check fuel cap or fuel tank
vapor vent (if equipped) for
leakage

Before each use

Clean air

fi

 lter

Every 25 hours of operation

Change air

fi

 lter

Every year or after 300
hours or operation

Clean spark plug

Every 6 months or after 100
hours of operation.

Replace spark plug

Every  year  or  after  300
hours of operation

Clean spark arrestor

Every 25 hours of operation

Replace spark arrestor

Every  year  or  after  300
hours of operation

Clean the exhaust port
and silencer

Every 25 hours of operation

1 These items should only be carried out by an authorised service
centre.
2 If this requirement is not met, contact an authorised service centre
for repair or adjustment.

REPLACING THE LINE IN THE STRING HEAD

RBC430SESD

See

fi

 gure 13.

RBC430SBD

See

fi

 gure 11.

■

Stop the engine.

■

Rotate the bump knob clockwise as necessary to align
the arrows on the bump knob with the arrows on the
string head housing.

■

Cut one piece of 2.4mm diameter trimmer line 5.4 m
long. Insert the line into the eyelet on the string head
housing. Push until the end of the line comes out the
other side of the housing. Pull the line until equal
amounts of line appear on both sides of the housing.

NOTE:

 Line may jam if more than 5.4 m is loaded.

■

Rotate the bump knob on the line trimer head to wind
the line.

■

Wind the string until approximately 20 cm remained
protruding from the string head.

CLEANING AIR FILTER SCREEN

RBC430SESD

See

fi

 gure 11.

RBC430SBD

See

fi

 gure 9.

■

For proper performance and long life, keep air filter
screen clean.

■

Remove the air filter cover by pushing down on the
latch with your thumb while gently pulling on the cover.

■

Remove the air filter.

■

Rinse, and let the air filter dry completely.

NOTE:

 If damaged, replace immediately.

■

Reinstall the foam filter.

■

Reinstall the air filter.

■

Replace the air filter cover by inserting the tabs on the
bottom of the cover into the slots on the air filter base;
push the cover up until it latches securely in place.

FUEL CAP

 WARNING

A leaking fuel cap is a

fi

 re hazard and must be replaced

immediately.

The fuel cap contains a non-serviceable

fi

 lter and a

check valve. A clogged fuel

fi

 lter will cause poor engine

performance. If performance improves when the fuel cap
is loosened, check valve may be faulty or

fi

 lter  clogged.

Replace fuel cap if required.

REPLACING THE SPARK PLUG

RBC430SESD

See

fi

 gure 15.

RBC430SBD

See

fi

 gure 13.

This engine uses a Champion RY4C or NGK CMR7A
spark plug with 0.6mm electrode gap. Use an exact
replacement and replace annually.

 CAUTION

Be careful not to cross-thread the spark plug. Cross-
threading will seriously damage the engine.

ADJUSTING CAMSHAFT-TO-ROCKER ARM
CLEARANCE

See

fi

 gure 14.

Inspect the camshaft-to-rocker arm clearance after every
25 hours of operation or if the engine can't go idle or if the
wide open throttle speed is too low. This should be done
in a clean, dust-free environment.

NOTE:

This procedure requires partial disassembly of the

engine. If you are unsure if you are quali

fi

 ed to perform this
