26
English (Original instructions)
ATTACHING THE GRASS DEFLECTOR
RBC430SESD:
See
fi
gure 5.
RBC430SBD:
See
fi
gure 3a.
■
Insert the two latches on the grass deflector to the
blade guard holes.
■
Align the screw on the grass deflector in the blade
guard hole.
■
Using the combination wrench supplied, tighten the
screw securely.
INSTALLING THE STRING HEAD
RBC430SBD
See
fi
gure 3b.
■
Place the combination wrench through the hole in the
upper flange washer and the hole in the gear box.
■
Align the nut in string head to gear box shaft.
■
Turn the string head counterclockwise by hand to
tighten, recommended torque is 6 N.M.
WARNING
Always stop the engine before making any adjustments,
such as changing cutting heads; this is to reduce the
risk of serious personal injury..
ATTACHING THE SHOULDER STRAP
NOTE:
Always use the shoulder strap with your
brushcutter.
See
fi
gure 1.
Follow these steps to attach the shoulder strap.
■
Connect the latch on the strap to the strap hanger.
■
Adjust the strap to a comfortable position.
NOTE:
To quickly release the product from the shoulder
strap, sharply pull the quick release tab.
CONVERTING FROM GRASS TRIMMER TO
BRUSHCUTTER (TRI-ARC BLADE)
RBC430SESD
See
fi
gure 6a.
RBC430SBD
See
fi
gure 4a.
When using the string head, the blade guard must be
attached with the grass de
fl
ector. When using the TRI-
ARC blade, the blade guard must be attached without the
grass de
fl
ector.
WARNING
To reduce the risk of serious personal injury, always
stop the engine before making any adjustments such
as changing cutting heads..
WARNING
Be certain all knobs and fasteners are fully tightened
before operating the equipment. Periodically check for
tightness during use to avoid serious injury.
REMOVING THE STRING HEAD
■
Stop the engine.
■
Use combination wrench to turn the screw on the
grass deflector counterclockwise to loose, and then
depress two latches on the grass deflector to remove
from the blade guard.
■
Place the combination wrench through the hole in the
upper flange washer and the hole in the gear head.
■
Turn the string head clockwise by hand to remove.
NOTE:
Store the disassembled parts together for later
use.
INSTALLING THE TRI-ARC BLADE
RBC430SESD
See
fi
gure 6a.
RBC430SBD
See
fi
gure 4a.
To reduce the risk of injury, keep the blade protector on
the blade at all times. Remove the blade protector only
during cutting operations.
■
Centre the blade on the upper flange washer and make
sure the blade sits flat. Install the cupped washer with
the raised centre away from the blade and make sure
it sits well into the gear shaft.
■
Align the two hooks on cupped washer into blade
washer holes.
■
Install the blade retainer nut until finger tight.
■
Place the combination wrench through the hole in
the upper flange washer and the hole in the gear
head. Using the wrench, turn the blade retainer nut
counterclockwise tight, recommended torque is 25
N.M.
CONVERTING FROM BRUSHCUTTER (TRI-ARC
BLADE) TO GRASS TRIMMER
RBC430SESD
See
fi
gure 6b.
