21

English (Original instructions)

 WARNING

To reduce the risk of serious personal injury, always
stop the engine before making any adjustments, such
as changing cutting heads.

CONVERTING FROM GRASS TRIMMER TO
BRUSHCUTTER (TRI-ARC™ BLADE)
Removing the ReelEasy™ grass trimmer head

See

fi

 gure 6.

1.  Stop the engine.
2. Open the ReelEasy™ Grass Trimmer Head by

depressing the latches on each side. The contents of
the bump head are spring loaded, so keep your other
hand over the string head cover while depressing the
latches.

3.  Remove the string head cover, bump knob, and line

spool.

4.  Place the Allen wrench through the hole in the upper

fl

 ange washer and the hole in the gear head. Using a

wrench, turn the drive connector clockwise to remove.

5.  Remove the drive connector and string head housing

from the gear head.

NOTE:

 Store the disassembled parts together for later

use.
6.  Remove the grass de

fl

 ector from the blade guard.

 WARNING

When using the Tri-Arc™ blade, the grass de

fl

 ector

must be removed from the blade guard.

See

fi

 gure 23.

Installing the Tri-Arc™ blade

See

fi

 gure 6.

 WARNING

Be certain all knobs and fasteners are fully tightened
before operating the product. Periodically check for
tightness during use to avoid serious injury.

 WARNING

Note that the blade nut is a nylon nut, which is to be
used for one time assembly only. Do not reuse the
nylon nut. When installing/reinstalling, use a new nylon
nut. Failure to follow this procedure can result in serious
injury.

To reduce the risk of injury, keep the blade protector on the
blade at all times. Remove the blade protector only during
cutting operations.

1.  Centre the blade on the upper

fl

 ange washer and

make sure the blade sits

fl

 at. Install the cupped

washer and make sure it sits well into the gear shaft.
Install the blade washer with the raised centre away
from the blade.

2.  Install the blade nut.
3.  Place the Allen wrench through the hole in the upper

fl

 ange washer and the hole in the gear head. Using the

wrench, turn the blade nut counterclockwise to tighten
(20 Nm).

CONVERTING FROM BRUSHCUTTER (TRI-ARC™
BLADE) TO GRASS TRIMMER
Removing the Tri-Arc™ blade

See

fi

 gure 7.

1.  Stop the engine.
2.  Place the Allen wrench through the hole in the upper

fl

 ange washer and the hole in the gear head. Turn

blade nut clockwise to remove.

3.  Remove the blade nut, blade washer, cupped washer,

and blade and retain for later use.

4.  Attach the grass de

fl

 ector to the blade guard by

placing the two locking tabs into the two notches;
tighten the screw.

NOTE:

 Store the disassembled parts together for later

use.

Installing the ReelEasy™ grass trimmer head

See

fi

 gure 7.

1.  Install the drive connector and string head housing

into the gear shaft. Place the Allen wrench through the
hole in the upper

fl

 ange washer and the hole in the

gear head. Using the wrench, turn the drive connector
counterclockwise to tighten securely.

2.  Reinstall the spool. For the straight shaft attachment

with the ReelEasy™ string trimmer head, the spool

should be placed so

is visible on the line spool.

3.  Replace the bump knob by inserting it into the centre

of the line spool.

4.  Replace the grass trimmer head cover, aligning latches

with openings in the grass trimmer head. Press cover
and grass trimmer head together until both latches
snap securely into the openings.

5.  Install the cutting line. Refer to "String replacement"

later in the manual for additional information.

6.  Install the grass de

fl

 ector into the blade guard.

 WARNING

When using the ReelEasy™ grass trimmer head, the
grass de

fl

 ector must be attached from the blade guard.

See

fi

 gure 24.
