23 ENGLISH

For nylon cutting head / plastic blade

CAUTION:

Take care not to injure yourself on

the cutter for cutting the nylon cord.

Attach the protector to the clamp using bolts. After

that, install the protector extension. Insert the protector

extension to the protector and then snap the clips on.

Make sure that the tabs on the protector extension fit

into the slots on the protector.

►

Fig.20:

1.

 Protector

2.

 Clip

3.

 Protector extension

4.

 Cutter

5.

 Slot

6.

 Tab

To remove the protector extension from the protec-

tor, unclasp the clips by inserting the hex wrench as

illustrated.

►

Fig.21:

1.

 Hex wrench

2.

 Clip

Installing the cutting tool

CAUTION:

Always use the supplied wrenches

to remove or to install the cutting tool.

CAUTION:

Be sure to remove the hex wrench

inserted into the tool head after installing the

cutting tool.

NOTE:

 The type of the cutting tool(s) supplied as

the standard accessory varies depending on the

countries. The cutting tool is not included in some

countries.

NOTE:

 Turn the tool upside down so that you can

replace the cutting tool easily.

Cutter blade

CAUTION:

When handling a cutter blade,

always wear gloves and put the blade cover on

the blade.

CAUTION:

The cutter blade must be well pol-

ished, and free of cracks or breakage.

 If the cutter

blade hits a stone during operation, stop the tool and

check the cutter blade immediately.

CAUTION:

Always use the cutter blade

with the diameter described in the section for

specifications.

►

Fig.22:

1.

 Nut

2.

 Cup

3.

 Clamp washer

4.

 Cutter

blade

5.

 Spindle

6.

 Receive washer

7.

 Hex

wrench

1.

  Insert the hex wrench through the hole in the gear

case to lock the spindle. Rotate the spindle until the hex

wrench is fully inserted.

2.

  Mount the cutter blade onto the receive washer

so that the arrows on the cutter blade and protector are

pointing in the same direction.

►

Fig.23:

1.

 Arrow

3.

  Put the clamp washer and cup onto the cutter

blade and then tighten the nut securely by the box

wrench.

►

Fig.24:

1.

 Box wrench

2.

 Hex wrench

3.

 Loosen

4.

 Tighten

NOTE:

 Tightening torque : 20 - 30 N•m

4.

  Remove the hex wrench from the gear case.

To remove the cutter blade, follow the installation proce-

dures in reverse.

Nylon cutting head

NOTICE:

Be sure to use genuine Makita nylon

cutting head.

There are two types of nylon cutting head; the bump &

feed type and the manual feed type.

Bump & feed type

►

Fig.25:

1.

 Nylon cutting head

2.

 Spindle

3.

 Hex

wrench

4.

 Loosen

5.

 Tighten

1.

  Insert the hex wrench through the hole in the gear

case to lock the spindle. Rotate the spindle until the hex

wrench is fully inserted.

2.

  Place the nylon cutting head onto the spindle and

tighten it securely by hand.

3.

  Remove the hex wrench from the gear case.

To remove the nylon cutting head, follow the installation

procedures in reverse.

Manual feed type

►

Fig.26:

1.

 Nut

2.

 Nylon cutting head

3.

 Spindle

4.

 Hex wrench

1.

  Insert the hex wrench through the hole in the gear

case to lock the spindle. Rotate the spindle until the hex

wrench is fully inserted.

2.

  Place the nylon cutting head onto the spindle and

tighten the nut securely by the box wrench.

►

Fig.27:

1.

 Box wrench

2.

 Hex wrench

3.

 Loosen

4.

 Tighten

3.

  Remove the hex wrench from the gear case.

To remove the nylon cutting head, follow the installation

procedures in reverse.

Plastic blade

NOTICE:

Be sure to use genuine Makita plastic

blade.

►

Fig.28:

1.

 Plastic blade

2.

 Spindle

3.

 Hex wrench

4.

 Loosen

5.

 Tighten

1.

  Insert the hex wrench through the hole in the gear

case to lock the spindle. Rotate the spindle until the hex

wrench is fully inserted.

2.

  Place the plastic blade onto the spindle and

tighten it securely by hand.

3.

  Remove the hex wrench from the gear case.

To remove the plastic blade, follow the installation pro-

cedures in reverse.
