Electronic function

Constant speed control

The speed control function provides the constant rota-

tion speed regardless of load conditions.

Soft start feature

Soft start because of suppressed starting shock.

ASSEMBLY

WARNING:

Always be sure that the tool is

switched off and battery cartridge is removed

before carrying out any work on the tool.

 Failure to

switch off and remove the battery cartridge may result

in serious personal injury from accidental start-up.

WARNING:

Never start the tool unless it is

completely assembled.

 Operation of the tool in a

partially assembled state may result in serious per-

sonal injury from accidental start-up.

Installing the handle

For DUR369A

1.

  Insert the shaft of the handle into the grip. Align

the screw hole in the grip with the one in the shaft.

Tighten the screw securely.

►

Fig.13:

1.

 Grip

2.

 Screw

3.

 Shaft

NOTICE:

Note the direction of the grip. The

screw holes will not be aligned if the grip is not

inserted in the correct direction.

2.

  Place handle between handle clamp and handle

holder. Adjust the handle to an angle that provides a

comfortable working position and then secure with hex

socket head bolts.

►

Fig.14:

1.

 Hex socket head bolt

2.

 Handle clamp

3.

 Handle holder

For DUR369L

1.

  Attach the upper and lower clamps on the damper.

2.

  Put the handle on the upper clamp and fix it with

hex socket head bolts as illustrated.

►

Fig.15:

1.

 Hex socket head bolt

2.

 Handle

3.

 Upper

clamp

4.

 Damper

5.

 Lower clamp

Attaching the barrier

For the loop handle model only (country specific)

If the barrier is included in your model, attach it to the

handle using the screw on the barrier.

►

Fig.16:

1.

 Barrier

2.

 Screw

CAUTION:

After assembling the barrier, do

not remove it.

 The barrier works as a safety part

to prevent you from contacting the cutting blade

accidentally.

Hex wrench storage

CAUTION:

Be careful not to leave the hex

wrench inserted in the tool head.

It may cause

injury and/or damage to the tool.

When not in use, store the hex wrench as illustrated to

keep it from being lost.

►

Fig.17:

1.

 Hex wrench

For the loop handle model, the hex wrench can also be

stored on the handle as illustrated.

►

Fig.18:

1.

 Hex wrench

Correct combination of the cutting

tool and the protector

CAUTION:

Always use the correct combi-

nation of cutting tool and the protector.

 A wrong

combination may not protect you from the cutting tool,

flying debris, and stones. It can also affect the bal

-

ance of the tool and result in an injury.

Cutting tool

Protector

Cutter blade

(2-tooth, 3-tooth, 4-tooth

blades)

Nylon cutting head

Plastic blade

Installing the protector

WARNING:

Never use the tool without the

guard or with the guard improperly installed.

Failure to do so can cause serious personal injury.

NOTE:

 The type of the protector supplied as the stan-

dard accessory varies depending on the countries.

For cutter blade

Attach the protector to the clamp using bolts.

►

Fig.19:

1.

 Clamp

2.

 Protector
