20 ENGLISH

FUNCTIONAL DESCRIPTION

WARNING:

Always be sure that the tool is

switched off and the battery cartridge is removed

before adjusting or checking function on the tool.

Failure to switch off and remove the battery cartridge may

result in serious personal injury from accidental start-up.

Installing or removing battery cartridge

CAUTION:

Always switch off the tool before

installing or removing of the battery cartridge.

CAUTION:

Hold the tool and the battery cartridge

firmly when installing or removing battery cartridge.

Failure to hold the tool and the battery cartridge firmly may

cause them to slip off your hands and result in damage to

the tool and battery cartridge and a personal injury.

►

Fig.5:

1.

 Red indicator

2.

 Button

3.

 Battery cartridge

To remove the battery cartridge, slide it from the tool

while sliding the button on the front of the cartridge.
To install the battery cartridge, align the tongue on the

battery cartridge with the groove in the housing and slip

it into place. Insert it all the way until it locks in place

with a little click. If you can see the red indicator on the

upper side of the button, it is not locked completely.

CAUTION:

Always install the battery cartridge

fully until the red indicator cannot be seen.

 If not,

it may accidentally fall out of the tool, causing injury to

you or someone around you.

CAUTION:

Do not install the battery cartridge

forcibly.

 If the cartridge does not slide in easily, it is

not being inserted correctly.

Tool / battery protection system

The tool is equipped with a tool/battery protection

system. This system automatically cuts off power to

the motor to extend tool and battery life. The tool will

automatically stop during operation if the tool is placed

under one of the following conditions:

Caution lamp

Status

Color

 On

 Blinking

Green

Overload

Red

 (tool) /

 (battery)

Overheat

Red

Over discharge

Overload protection

If the tool gets into one of the following situation, the tool auto-

matically stops and the caution lamp starts blinking in green:
—  The tool is overloaded by entangled weeds or other debris.
—  The cutting tool is locked or kicked back.
—  The main power button is turned on while the

switch trigger is being pulled.

In this situation, release the switch trigger and remove

entangled weeds or debris if necessary. After that, pull

the switch trigger again to resume.

CAUTION:

If you need to remove the entan-

gled weeds on the tool or release the locked

cutting tool, be sure to turn the tool off before you

start.

Overheat protection for tool or battery

If the tool or battery cartridge is overheated, the tool

stops automatically. When the tool is overheated, the

caution lamp lights up in red. When the battery cartridge

is overheated, the caution lamp blinks in red. Let the tool

and/or battery cool down before turning the tool on again.

Overdischarge protection

When the battery capacity becomes low, the tool stops

automatically and the caution lamp starts blinking in red.

If the tool does not operate even when the switches are

operated, remove the battery cartridge from the tool and

charge it.

Indicating the remaining battery capacity

Only for battery cartridges with the indicator

►

Fig.6:

1.

 Indicator lamps

2.

 Check button

Press the check button on the battery cartridge to indi-

cate the remaining battery capacity. The indicator lamps

light up for a few seconds.

Indicator lamps

Remaining

capacity

Lighted

Off

Blinking

75% to 100%

50% to 75%

25% to 50%

0% to 25%

Charge the

battery.

The battery

may have

malfunctioned.

NOTE:

 Depending on the conditions of use and the

ambient temperature, the indication may differ slightly

from the actual capacity.

NOTE:

 The first (far left) indicator lamp will blink when

the battery protection system works.

Main power switch

Tap the main power button to turn on the tool.

To turn off the tool, press and hold the main power

button until the speed indicator goes off.

►

Fig.7:

1.

 Speed indicator

2.

 Main power button

NOTE:

 The tool will automatically turned off if it is left

without any operations for a certain period of time.
