20

 | English

F 016 L70 778 | (27.10.10)

Bosch Power Tools

f

Children or persons with mental or physical
limitations may only use the charger under
supervision or after having been instructed.

A thorough introduction reduces operating
errors and injuries.

Products sold in

GB only

: Your product is fitted

with an BS 1363/A approved electric plug with
internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets,
it should be cut off and an appropriate plug fit-
ted in its place by an authorised customer serv-
ice agent. The replacement plug should have the
same fuse rating as the original plug.
The severed plug must be disposed of to avoid a
possible shock hazard and should never be in-
serted into a mains socket elsewhere.

Functional Description

Read all safety warnings and all in-
structions.

Failure to follow the

warnings and instructions may re-
sult in electric shock, fire and/or se-
rious injury.

Intended Use

The machine is intended for the cutting of grass
and weeds under bushes, as well as on slopes
and edges that can not be reached with the lawn
mower.
Intended use is related to operation within 0 ° C
and 40 ° C ambient temperature.

Delivery Scope

Carefully remove the garden product from its
packaging and check if the following parts are
complete:
– Cordless trimmer
– Blade guard
– Adjustable handle (fitted)
– Cutting disc
– Blade
– Operating instructions

Battery and charger are included in certain exe-
cutions.
When parts are missing or damaged, please con-
tact your dealer.

Product Features

The numbering of the garden product features
refers to the illustration of the garden product
on the graphics page.

1

On/Off switch

2

Lock-off button for On/Off switch

3

Handle

4

Handle screw

5

Adjustable handle

6

Adjusting collar

7

Shaft

8

Ventilation slots

9

Trimmer head

10

Blade

11

Blade guard

12

Foot pedal for trimmer-head angle adjust-
ment

13

LED indicator

14

Battery charger

15

Battery

16

Serial number

17

Cutting disc

18

Pin

19

Plant protector

Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.
