Sony KV-32FX66K - Инструкция по эксплуатации - Страница 24

24

Specifications

Additional Information

Design and specifications are subject to change without notice.

Ecological Paper - Totally Chlorine Free

  (SMARTLINK)

Sony España, S.A., hereby declares that this Colour TV is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC.
www.compliance.sony.de

TV system:

Depending on your country
selection:
B/G/H, D/K

Colour system:

PAL
SECAM, NTSC 3.58, 4.43 (only
Video In)

Channel Coverage:

VHF: E2-E12
UHF: E21-E69
CATV: S1-S20
HYPER: S21-S41
D/K: R1-R12,

R21-R69

Picture Tube:

Flat Display FD Trinitron
WIDE: 32” (approx. 82 cm.
measured diagonally)

Rear Terminals

1

/

1

21-pin scart

 connector

(CENELEC standard)

  including audio/video

input, RGB input, TV
audio/video output.

2

/

2

 21-pin

Scart

 connector

(CENELEC standard)

  including audio / video

input, RGB input, monitor
audio/video output.

3

/

3

 21-pin

Scart

 connector
 (CENELEC

standard) including
audio / video input, S video
input, selectable
audio / video output and
Smartlink interface.

     audio outputs (Left/
     Right) - phono jacks

Side Terminals

4

S Video input – 4 pin
DIN

4

   video input – phono

jack

4

   audio input – phono

jacks

headphones jack

Sound Output:

2 x 20 W (music power)
2 x 10 W (RMS)

Woofer:

30 W (music power)
15 W (RMS)

Power Consumption:

130 W

Standby Power
Consumption:

0.3 W

Dimensions (w x h x d) :

approx. 882 x 567 x 562 mm.

Weight:

approx. 63 Kg.

Remote Control Locator
coverage:

up to 10 m. in open field

The optimum distance is

up to approximately 10

meters without interference.
However, the distance may
vary according to the
surroundings and
environment.

Even within the signal

reception area, there are

some spots (dead spot) where
the RF signal can not be
received. This characteristics is
inherent to RF signals, and
does not indicate malfunction.

Remote Control Locator
Frequency:

434 MHz (ISM band).

The frequency of your

 Remote

Control

Locator

may be used by other devices
(e.g. electric garage door). If
the use of the Remote Control
Locator causes interferences
with any other device(s) please
contact your nearest Sony
Service Centre.

Accessories supplied:

1 Remote Control (RM-937)
3 Batteries (IEC designated,

AA size)

Other features:

• 100 Hz picture, Digital Plus.
• Teletext, Fastext, TOPtext

(250 page TEXT  memory).

• Sleep Timer.
• Smartlink (direct link

between your TV set and a
compatible VCR. For more
information on Smartlink,
please refer to the
Instruction Manual of your
VCR).

• TV system autodetection.
• Dolby Virtual.
• BBE.
• PIP.
• Auto Format.
• ACI (Auto Channel
 Installation).
• Remote Control Locator.
