ENGLISH

(Original instructions)

6

as, but not limited to, grinding dust, metal chips,

steel wool, aluminum foil, or any buildup of

metallic particles should be kept away from

charger cavities. Always unplug the charger

from the power supply when there is no battery

pack in the cavity. Unplug charger before

attempting to clean.

♦

DO NOT attempt to charge the battery pack with

any chargers other than the ones in this manual.

The charger and battery pack are specifically designed

to work together.

♦

These chargers are not intended for any uses other

than charging STANLEY rechargeable batteries.

Any other uses may result in risk of fire, electric shock

or electrocution.

♦

Do not expose charger to rain or snow.

♦

Pull by plug rather than cord when disconnecting

charger.

This will reduce risk of damage to electric plug

and cord.

♦

Make sure that cord is located so that it will not be

stepped on, tripped over, or otherwise subjected to

damage or stress.

♦

Do not use an extension cord unless it is absolutely

necessary.

Use of improper extension cord could

result in risk of fire, electric shock, or electrocution.

♦

Do not place any object on top of charger or place

the charger on a soft surface that might block the

ventilation slots and result in excessive internal

heat.

 Place the charger in a position away from any

heat source. The charger is ventilated through slots in

the top and the bottom of the housing.

♦

Do not operate charger with damaged cord or plug

— have them replaced immediately.

♦

Do not operate charger if it has received a sharp

blow, been dropped, or otherwise damaged in any

way.

 Take it to an authorised service centre.

♦

Do not disassemble charger; take it to an

authorised service centre when service or repair is

required.

 Incorrect reassembly may result in a risk of

electric shock, electrocution or fire.

♦

In case of damaged power supply cord the supply cord

must be replaced immediately by the manufacturer, its

service agent or similar qualified person to prevent any

hazard.

♦

Disconnect the charger from the outlet before

attempting any cleaning. This will reduce the risk

of electric shock.

 Removing the battery pack will not

reduce this risk.

♦

NEVER

 attempt to connect 2 chargers together.

♦

The charger is designed to operate on standard

household electrical power. Do not attempt to use

it on any other voltage.

 This does not apply to the

vehicular charger.

SAVE THESE INSTRUCTIONS

Chargers

The SC201/ SC202 accept 18V batteries.

These chargers require no adjustment and are designed to

be as easy as possible to operate.

Charging Procedure (fig. B)

1.  Plug the charger into an appropriate outlet before

inserting battery pack.

2.  Insert the battery pack (6) into the charger. The red

(charging) light will blink continuously indicating that the

charging process has started.

3.  The completion of charge will be indicated by the red

light remaining ON continuously. The pack is fully

charged and may be used at this time or left in the

charger.

Note:

 To ensure maximum performance and life of Li-Ion

batteries, charge the battery pack fully before first use.

Charging Process

Refer the tables below for the state of charge of the battery

pack.

State of charge–SC201/SC202

charging                          ―     ―     ―     ―

fully charged

hot/cold pack delay         ―     ―     ―  │

Hot/Cold Pack Delay
SC201/ SC202

When the charger detects a battery that is hot, it

automatically delays charging until the battery has cooled.

When the charger detects a battery that is cold, it

automatically delays charging until the battery has warmed.

The red light will continue to blink, but a yellow indicator

light will be illuminated during this operation. Once the

battery has cooled, the yellow light will turn off and the

charger will resume the charging procedure.

Stanley Li-Ion tools are designed with an Electronic

Protection System that will protect the battery against

overloading, overheating or deep discharge.

The tool will automatically turn off if the Electronic

Protection System engages. If this occurs, place the Li-Ion

battery on the charger until it is fully charged.

Li-Ion BATTERY PACKS ONLY

Li-Ion batteries are designed with an Electronic Protection

System that will protect the battery against overloading,

overheating or deep discharge.
