Product Description and Specifica-
tions

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for cutting, roughing and brushing of
metal and stone materials without the use of water.
For cutting with bonded abrasives, a special cutting guard
(accessory) must be used.
When cutting in stone, provide for sufficient dust extraction.
With approved sanding tools, the machine can be used for
sanding with sanding discs.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Spindle lock button

2

On/Off switch

3

Auxiliary handle (insulated gripping surface)

4

Grinder spindle

5

Mounting flange with O-ring

6

Grinding wheel *

7

Clamping nut

8

Two-pin spanner for clamping nut *

9

Quick-clamping nut

*

10

Carbide grinding head *

11

Cutting disc *

12

Hand guard *

13

Spacer discs *

14

Rubber sanding plate *

15

Sanding sheet *

16

Round nut *

17

Cup brush *

18

Cutting guide with dust extraction protection guard *

19

Diamond cutting disc *

20

Handle (insulated gripping surface)

21

Protection guard for grinding (clamping screw)

22

Locking screw for protection guard

23

Protection guard for cutting (clamping screw) *

24

Protection guard for grinding cup *

25

Grinding cup *

26

Two-pin spanner, offset, for grinding cup *

27

Vibration damper

28

Protection guard for grinding

29

Encoding key

30

Clamping lever for protection guard

31

Screw for adjustment of protection guard

32

Protection guard for cutting

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Technical Data

Angle Grinder

GWS ...

22-180

H

22-230

H

22-230

JH

24-180

H

Article number

3 601 ...

H81 1..

H82 1..

H82 2..

H83 1..

Rated power input

W

2 200

2 200

2 200

2 400

Output power

W

1 500

1 500

1 500

1 600

Rated speed

min

-1

8 500

6 500

6 500

8 500

Grinding disc diameter, max.

mm

180

230

230

180

Thread of grinder spindle

M 14

M 14

M 14

M 14

Thread length (max.) of grinder spindle

mm

25

25

25

25

Reduced starting current

–

–



–

Rotatable main handle

–

–

–

–

Run-on Brake

–

–

–

–

Weight according to EPTA-Procedure 01:2014
– with vibration-damping auxiliary handle
– with standard-auxiliary handle

kg
kg

5.1
5.0

5.1
5.0

5.3
5.2

5.0
4.9

Protection class

/

II

/

II

/

II

/

II

Angle Grinder

GWS ...

24-230

H

24-230

JH

26-180

H

Article number

3 601 ...

H84 1..

H84 2..

H55 1..

Rated power input

W

2 400

2 400

2 600

Output power

W

1 600

1 600

1 700
