SPECIFICATIONS

41

 En

ADDITION

AL IN

FORMATION

5

Eng

lish

Linear PCM Sound

Linear PCM is a signal recording format used for Audio
CDs and on some DVD and Blu-ray discs. The sound on
Audio CDs is recorded at 44.1 kHz with 16 bits. (Sound
is recorded between 48 kHz with 16 bits and 96 kHz
with 24 bits on DVD discs and between 48 kHz with 16
bits and 192 kHz with 24 bits on BD discs.)

Lip Sync

Lip Sync, an abbreviation for lip synchronization, is a
technical term that involves both a problem and a
capability of maintaining audio and video signals
synchronized during post-production and transmission.
Whereas the audio and video latency requires complex
end-user adjustments, HDMI version 1.3 incorporates
an automatic audio and video syncing capability that
allows devices to perform this synchronization
automatically and accurately without user interaction.

Mac address

The Mac address is a unique value assigned to a network
device for identification purposes.

Pan Scan (PS 4:3)

A screen size that cuts off the sides of the image to allow
viewing of wide-screen (16:9) material on a connected
4:3 TV.

Subtitles

These are the lines of text appearing at the bottom of the
screen which translate or transcribe the dialog. They are
recorded on many DVD and BD discs.

Top menu

In a BD-Video/DVD-Video, this is the menu for
selecting things like the chapter to be played back and
the subtitle language. In some DVD-Videos, the top
menu may be called the “Title Menu”.

x.v.Color

x.v.Color reproduces a greater range of color than
before, showing almost all of the colors that the human
eye can detect.

■

General

Power supply

[Central and South America models] ................ AC 110–240 V, 50/60 Hz
[Europe and Russia models]........................................... AC 230 V, 50 Hz
[Asia model] ...................................................... AC 220–240 V, 50/60 Hz
[Taiwan model] ................................................. AC 110-120 V, 50/60 Hz
[Korea model] ................................................................ AC 220 V, 60 Hz

Power consumption (Normal) .............................................................. 25 W
Power consumption (Standby) ................................................. 0.5 W or less
Dimensions (W × H × D)  ............................................. 435 × 96 × 316 mm

(17-1/8 × 3-3/4 × 12-1/2 in)

Weight .............................................................................. 4.05 kg (8.93 lbs.)

■

Audio performance

Audio output level (1 kHz, 0 dB, BD/DVD/CD-DA) .................... 2 ± 0.3 V
Signal to nose ratio (BD/DVD/CD-DA) .............................. 115 dB or more
Dynamic range

BD/DVD ........................................................................... 105 dB or more
CD-DA .............................................................................. 100 dB or more

Harmonic distortion (1 kHz)

BD/DVD ......................................................................... 0.0028 % or less
CD-DA .............................................................................. 0.003 % or less

Frequency response

BD/DVD ............................................ 2 Hz to 22 kHz (48 kHz Sampling)

2 Hz to 44 kHz (96 kHz Sampling)

CD-DA ...............................................................................2 Hz to 20 kHz

■

Input/output

HDMI output .............................................................. Type A connector × 1

480i/576i/480p/576p/720p/1080i/1080p/1080p@24Hz,

Deep Color, x.v. Color support

Component video output ..............................................Y: 1 Vp-p (75 ohms)

P

B

, P

R

: 0.7 Vp-p (75 ohms)

Video output ......................................................................1 Vp-p (75 ohms)
Digital output.......................................................... Optical × 1, Coaxial × 1
Analog audio output ..................................................................... 7.1 ch × 1,

Mixed 2 ch × 1

USB ............................................................................ Type A connector × 2
Other output equipments ............................................. Remote IN/OUT × 1,

RS-232C × 1 (for custom installer),

Ethernet × 1

Specifications are subject to change without notice.
