Use suitable detectors to determine if utility lines are
hidden in the work area or call the local utility company
for assistance.

Contact with electric lines can lead to fire

and electric shock. Damaging a gas line can lead to explo-
sion. Penetrating a water line causes property damage or
may cause an electric shock.



Do not operate the power tool stationary.

It is not de-

signed for operation with a saw table.



Do not use high speed steel (HSS) saw blades.

Such saw

blades can easily break.



Do not saw ferrous metals.

Red hot chips can ignite the

dust extraction.



When working with the machine, always hold it firmly
with both hands and provide for a secure stance.

The

power tool is guided more secure with both hands.



Secure the workpiece.

A workpiece clamped with clamp-

ing devices or in a vice is held more secure than by hand.



Always wait until the machine has come to a complete
stop before placing it down.

The tool insert can jam and

lead to loss of control over the power tool.

Products sold in GB only

: Your product is fitted with a

BS 1363/A approved electric plug with internal fuse (ASTA
approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an author-
ised customer service agent. The replacement plug should
have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains sock-
et elsewhere.

Products sold in AUS and NZ only

: Use a residual current de-

vice (RCD) with a rated residual current of 30 mA or less.

Product Description and Specifica-
tions

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

Intended Use

The machine is intended for lengthways and crossways cut-
ting of wood with straight cutting lines as well as mitre cuts in
wood while resting firmly on the workpiece. With suitable saw
blades, thin-walled non-ferrous metals, e. g., profiles, can al-
so be sawed.
Working ferrous metals is not permitted.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Thumbwheel for speed preselection  (GKS 55+ GCE)

2

On/Off switch

3

Lock-off button for On/Off switch

4

Hex key

5

Spindle lock button

6

Scale for mitre angle

7

Wing bolt for parallel guide

8

Wing bolt for bevel-angle preselection

9

Cutting mark, 45 °

10

Cutting mark, 0 °

11

Parallel guide *

12

Retracting blade guard

13

Lever for retracting blade guard

14

Base plate

15

Wing bolt for bevel-angle preselection
(GKS 55+ G / GKS 55+ GCE)

16

Chip ejector

17

Blade guard

18

Handle (insulated gripping surface)

19

Auxiliary handle (insulated gripping surface)

20

Clamping bolt with washer

21

Clamping flange

22

Saw blade *

23

Mounting flange

24

Saw spindle

25

Fastening screw for extraction adapter *

26

Extraction adapter *

27

Clamping lever for cutting-depth preselection

28

Cutting-depth scale

29

Set of screw clamps **

30

Guide rail *

31

Vacuum hose *

32

Connection piece *

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

** Commercially available (not included in the delivery scope)
