English |
17
Bosch Power Tools
1 609 929 V37 | (22/6/10)
Technical Data
Declaration of Conformity
We declare under our sole responsibility that
the product described under “Technical Data” is
in conformity with the following standards or
standardization documents: EN 60745 accord-
ing to the provisions of the directives
2004/108/EC, 2006/42/EC.
Technical file at:
Robert Bosch GmbH, PT/ESC,
D-70745 Leinfelden-Echterdingen
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Leinfelden, 22.06.2010
Assembly
f
Before any work on the machine itself, pull
the mains plug.
Auxiliary Handle
f
Operate your machine only with the auxilia-
ry handle 5.
The auxiliary handle
5
can be set to any position
for a secure and low-fatigue working posture.
– Turn the bottom part of the auxiliary handle
5
in counterclockwise direction and swivel
the auxiliary handle
5
to the desired position.
Then retighten the bottom part of the auxilia-
ry handle
5
by turning in clockwise direction.
Rotary Hammer
GBH 5-38 D Professional
GBH 500 Professional
Article number
0 611 240 0..
Rated power input
W
1 050
Rated speed
min
-1
320
Impact rate
min
-1
2 900
Impact energy per stroke according to EPTA-Procedure
05/2009
J
5.9
Chisel positions
12
Chiselling capacity in concrete of medium hardness
kg / h
110
Tool holder
SDS-max
Lubrication
Oil lubrication
Max. drilling dia.
– Concrete (with twist drill)
– Concrete (with break-through drill bit)
– Brickwork (with core bit)
mm
mm
mm
38
55
90
Weight according to EPTA-Procedure 01/2003
kg
5.8
Protection class
/
II
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries,
these values can vary.
Please observe the article number on the type plate of your machine. The trade names of the individual machines
may vary.
Dr. Egbert Schneider
Senior Vice President
Engineering
Dr. Eckerhard Strötgen
Head of Product
Certification
OBJ_BUCH-273-002.book Page 17 Tuesday, June 22, 2010 11:24 AM
