In case of damage and improper use of the battery, va-
pours may be emitted. Ventilate the area and seek
medical help in case of complaints.

The vapours can irri-

tate the respiratory system.



Use the battery only in conjunction with your Bosch
power tool.

This measure alone protects the battery

against dangerous overload.



The battery can be damaged by pointed objects such as
nails or screwdrivers or by force applied externally.

An

internal short circuit can occur and the battery can burn,
smoke, explode or overheat.

Product Description and Specifica-
tions

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for hammer drilling in concrete,
brick and stone, as well as for light chiselling work. It is also
suitable for drilling without impact in wood, metal, ceramic
and plastic. Machines with electronic control and right/left ro-
tation are also suitable for screwdriving.

The light of this power tool is intended to illuminate the power
tool’s direct area of working operation and is not suitable for
household room illumination.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Quick change keyless chuck  (GBH 18V-26 F)

2

SDS-plus quick change chuck  (GBH 18V-26 F)

3

SDS-plus tool holder

4

Dust protection cap

5

Locking sleeve

6

Lock ring for rapid-change chuck  (GBH 18V-26 F)

7

Vibration damper

8

Rotational direction switch

9

Handle (insulated gripping surface)

10

On/Off switch

11

Battery pack *

12

Release button for mode selector switch

13

Mode selector switch

14

Worklight

15

Button for depth stop adjustment

16

Auxiliary handle (insulated gripping surface)

17

Depth stop

18

Battery unlocking button

19

EPC switch (Electronic Precision Control)

20

Button for charge-control indicator

21

Battery charge-control indicator

22

Mounting for suspension strap

23

Securing screw for key type drill chuck  (GBH 18V-26) *

24

Key type drill chuck  (GBH 18V-26) *

25

SDS-plus adapter shank for drill chuck
 (GBH 18V-26) *

26

Drill chuck mounting  (GBH 18V-26 F)

27

Identification grooves

28

Chuck key (GBH 18V-26)

29

Front sleeve of the quick change keyless chuck
(GBH 18V-26 F)

30

Retaining ring of the quick change keyless chuck
(GBH 18V-26 F)

31

Universal bit holder with SDS-plus shank *

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Noise/Vibration Information

Sound emission values determined according to
EN 60745-2-6.

Typically the A-weighted noise levels of the product are:
Sound pressure level 91 dB(A); sound power level
102 dB(A).  Uncertainty  K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745-2-6:

GBH 18V-26

Hammer drilling into concrete: a

h

= 13.0 m/s

2

, K= 1.5 m/s

2

Chiselling: a

h

= 8.5 m/s

2

, K = 1.5 m/s

2

Drilling into metal: a

h

= 2.5 m/s

2

, K = 1.5 m/s

2

Screwdriving without impact: a

h

= 2.5 m/s

2

, K = 1.5 m/s

2

GBH 18V-26 F

Hammer drilling into concrete: a

h

= 12.5 m/s

2

, K= 1.5 m/s

2

Chiselling: a

h

= 9.0 m/s

2

, K = 1.5 m/s

2

Drilling into metal: a

h

= 2.5 m/s

2

, K = 1.5 m/s

2

Screwdriving without impact: a

h

= 2.5 m/s

2

, K = 1.5 m/s

2

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.
