EN


L-L 230.03-BM

27 / 64

IMPORTANT

Before using the space heater, carefully read all of the instructions and follow them scrupulously. The manufacturer cannot be

held responsible for damage to persons and/or property caused by improper use of the equipment.

This instruction manual is an integral part of the equipment and must therefore be stored carefully and passed on with the unit in

the event of a change of ownership.

1. DESCRIPTION

The space heaters described in this manual are designed to heat

medium or large-size rooms requiring a fixed heating system and, in

particular, to heat greenhouses and/or rooms for breeding animals.

The air required for combustion is sucked directly by the burner (6)

installed on the heater, and can be supplied:

•  from the outside by using the flexible connection tube (available

as an accessory), which avoids consuming oxygen in the room to

be heated, or

•  from inside the room to be heated. In this case, the room must be

well ventilated to guarantee sufficient exchange of air.

The flow of hot air is moved by the high-efficiency fan (4): air is

heated by the thermal energy generated during la combustion and

heat from the smoke is transmitted to the fresh air through the

metal walls of the sealed combustion chamber and the heat

exchanger.

After the combustion products are cooled, they are conveyed to a

discharge duct and eliminated through a chimney or flue large

enough to guarantee their removal.

The space heaters can work with burners having ON-OFF work

modes and can run on diesel fuel.

Warning

Only burners approved by the manufacturer and listed in

the “TECHNICAL SPECIFICATION TABLE” can be used.

The heater’s certification and warranty will lapse if the

burner is replaced with a non-original model, even if it has

similar specifications.

All of the space heaters are fit with an electronic device that

controls the flame and with:

• safety devices (safety thermostat with manual reset, flame

control, air pressure switch) that trip in case of serious

malfunctions and cause a safety stop. In this case the heater

stops, button (d) lights with a steady red light (Stop Light) and the

heater can resume operation only after the cause of the stop has

been identified and eliminated;

• control devices (fan thermostat, burner thermostat, voltage

control, gas pressure switch) that trip in case of minor operating

faults or supply faults, causing temporary stop of the space

heater. In this case, the heater will restart automatically when the

required condition is restored.

The section “TROUBLESHOOTING” describes all possible operating

faults and their possible remedies.

2. CONDITIONS OF SUPPLY

Space heaters can be supplied:

•  fully assembled and packaged, ready for installation, or

• disassembled into main parts or groups to be assembled

following separately supplied assembly instructions. In this case,

the following are provided:

• Central machine body

•  Electrical panel group + thermostat unit

• Motor-fan group

• Diesel burner

•  Group assembly manual

• Any accessories requested (flue pipes, air distribution pipes,

etc.)

Warning

Prior to installation, burner adjustment and ignition, the

space heater should be assembled in full.

All assembly operations should only be performed by

professionally qualified personnel only.

Warning

Upon completing assembly, the identification labels

provided in the following packaging:

•

electrical panel unit

•

motor-fan unit

•

diesel burner

should be applied both on the space heater's serial

number label and on the declaration of assembly and

installation on the penultimate page of this manual.

The following are also supplied:

•  use and maintenance manuals for

• space heater

• burner

•  manuals with drawings and replacement part lists:

• space heater

• burner

• electrical panel

• motor-fan unit

Warning

All documents provided constitute an integral part of the

unit.

The documents should therefore be looked after with care

and supplied with the unit in the event of a change in

ownership.

Parts are to be transported and moved using either a manual or

automatic forklift truck with sufficient load capacity.

Warning

Never try to lift the heater manually. Doing so could cause

serious physical injury.

3. GENERAL ADVICE

The space heater must be installed, adjusted, and used in

conformity to national and local laws and regulations for its

operation.

General guidelines:

•  Follow the instructions in this booklet very carefully;

•  The heater is not installed in an area where there is a high risk of

fire or explosions;

•  Keep inflammable material at a safe distance from the heater

(minimum 3 metres);

•  Check that there is no overheating of walls, ceilings or floors made

of inflammable materials,

•  All precautions have been taken to prevent fires;

•  The room being heated must be sufficiently ventilated so that the
