 23

en

Before using for the first time

Before using for the first time

Before the new appliance can be used,

it must be fully unpacked, cleaned and

checked.

Caution!

Never operate a damaged appliance!

■

Remove the base unit and all

accessories from the packaging.

■

Remove the packaging material that is

present.

■

Dismantle any assembled parts into

their individual parts. Do this in reverse

order, as described under „Preparation“.

■

Check all parts for completeness.

X

Fig.

A

■

Inspect all parts for visible damage.

■

Thoroughly clean and dry all parts

before using for the first time.

X

 “Care and daily cleaning” see

page 26

Control and display

elements

Button

k

Press button

k

 to switch on the appliance.

The drive will start up at once. Press button

k

 again to switch off the appliance. The

drive stops.

Release button

Press the release button to unlock an

attachment fitted on the appliance. Only

when the release button is pressed is it

possible to turn the attachment clockwise

and remove it from the base unit.

Safety devices

Thermal circuit breaker

If the motor switches itself off while the

appliance is being used, the overload

protection feature has been activated.

Possible causes may be the simultaneous

processing of large quantities of food or a

blockage caused by bones.

X

 “Troubleshooting” see page 30

Overload protection

To prevent serious damage to your

appliance if the base attachment is

overloaded, the agitator paddle has a

notch (predetermined breaking point). If

overloading occurs, the agitator paddle

will break at this point. A new agitator

paddle is available from Customer

Service (No. 10011109). Spare parts with

a predetermined breaking point are not

covered by our warranty obligations.

Replace agitator paddle

X

Fig.

E

1.

Release the screw in the agitator paddle

with a screwdriver (PH2) and remove

the faulty paddle.

2.

Fit a new agitator paddle and screw tight

again.

Base unit

Preparation

W

Risk of injury!

Do not insert the mains plug until all

preparations for working with the appliance

are complete and the required attachments

are assembled correctly and connected to

the base unit.

■

Place the base unit on a stable and level

work surface.

The base unit is now prepared.

Base attachment

The base attachment can be used for the

following   applications:

Meat mincer

For mincing raw or cooked food. Select the

appropriate perforated disc depending on

the type and consistency of the food to be

processed.

X

 “Tips” see page 28

Sausage filler

For filling artificial and natural casings with

sausage meat. For producing meat rolls.

Kebbe maker

For producing tubes of dough or minced meat.
