4

Specifications

Specifications

CPU

Supports AM4 socket 3rd Gen AMD Ryzen™ processors, and

future AMD Ryzen™ processors with BIOS update

Chipset

AMD B550 Chipset

Memory

∙

4x DDR4 memory slots, support up to 128GB*

▪

Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/

3000/ 3066/ 3200 MHz by JEDEC

▪

Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200

/3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400 /4533

/4600 /4733/ 4800/ 4866+  MHz by A-XMP OC MODE

▫

1DPC 1R max speed 4866 MHZ

▫

1DPC 2R max speed 3866 MHZ

▫

2DPC 1R max speed 4000 MHZ

▫

2DPC 2R max speed 3600 MHZ

∙

Dual channel memory architecture

∙

Supports non-ECC UDIMM memory

∙

Supports ECC UDIMM memory (non-ECC mode)

∙

Supports un-buffered memory

* Please refer www.msi.com for more information on compatible memory.

Expansion Slot

∙

1x PCIe 4.0/ 3.0 x16 slot (PCI_E1)*

∙

1x PCIe 3.0 x16 slot (PCI_E3), supports x4 speed**

∙

2x PCIe 3.0 x1 slots

* The supported specification depends on installed processor.
** When installing devices in M.2_2, PCI_E2 & PCI_E3 slots at the same time,

PCI_E3 slot will be unavailable, and M2_2 slot only supports PCIe x2. Please

refer to page 16 for details.

Multi-GPU

∙

Supports 2-Way AMD CrossFire™ Technology

Onboard Graphics

∙

1x HDMI port, supports a maximum resolution of

4096x2160 @24Hz*

∙

1x DisplayPort, supports a maximum resolution of

4096x2160 @60Hz*

∙

Maximum shared memory of 2048 MB

* Available for the processor with integrated graphics.

Continued on next page
