Specifications

Continued from previous page

Audio

Realtek® ALC897 Codec

∙

7.1-Channel High Definition Audio

LAN

1x Intel® I219V 1Gbps LAN controller

Storage

∙

4x SATA 6Gb/s ports (From H510/ B560 Chipset)

∙

1x M.2 slot (Key M) (For H510M PRO/ H510M-A PRO/ H510M

BOMBER/ B560M PRO-E/ B560M PLUS)

▪

M2_1 slot (From H510/ B560 Chipset)*

▫

Supports up to PCIe 3.0 x4

▫

Supports SATA up to 6Gb/s

▫

Supports 2242/ 2260/ 2280 storage devices

* SATA4 will be unavailable when installing M.2 SATA SSD in

the M2_1 slot.

USB

∙

Intel® H510/ B560 Chipset

▪

4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the

back panel, 2 ports available through the internal  USB

connector)

▪

6x USB 2.0 ports (4 Type-A ports on the back panel(hub-

GL850G), 2 ports available through the internal USB 2.0

connector)

Internal

Connectors

∙

1x 24-pin ATX main power connector

∙

1x 8-pin ATX 12V power connector

∙

4x SATA 6Gb/s connectors

∙

1x USB 3.2 Gen 1 5Gbps connector (supports additional 2

USB 3.2 Gen 1 5Gbps ports)

∙

1x USB 2.0 connector (supports additional 2 USB 2.0 ports)

∙

1x 4-pin CPU fan connector

∙

1x 4-pin system fan connector

∙

1x front panel audio connector

∙

2x system panel connectors

∙

1x serial port connector

∙

1x Chassis Intrusion connector

∙

1x Clear CMOS jumper

∙

1x TPM module connector

Continued on next page
