3

Specifications

Specifications

CPU

Supports AM4 socket 3rd Gen AMD Ryzen™ processors, and

future AMD Ryzen™ processors with BIOS update

Chipset

AMD B550 Chipset

Memory

∙

4x DDR4 memory slots, support up to 128GB*

▪

Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/

3000/ 3066/ 3200 MHz by JEDEC

▪

Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200

/3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400+ MHz by

A-XMP OC MODE

▫

1DPC 1R max speed 4400 MHZ

▫

1DPC 2R max speed 3733 MHZ

▫

2DPC 1R max speed 3866 MHZ

▫

2DPC 2R max speed 3466 MHZ

∙

Dual channel memory architecture

∙

Supports non-ECC UDIMM memory

∙

Supports ECC UDIMM memory

∙

Supports un-buffered memory

* Please refer www.msi.com for more information on compatible memory.

Expansion Slot

∙

1x PCIe 3.0/ 4.0 x16 slot (PCI_E1)*

∙

2x PCIe 3.0 x1 slots

* The supported specification depends on installed processor.

Onboard Graphics

∙

1x VGA port, supports resolution of 2048x1536 @50Hz,

2048x1280 @60Hz, 1920x1200 @60Hz*

∙

1x DisplayPort, supports a maximum resolution of

4096x2160 @60Hz*

∙

1x HDMI port, supports a maximum resolution of

4096x2160 @24Hz*

∙

Maximum shared memory of 16 GB

* Available for the processor with integrated graphics.

Continued on next page
