Unique Features
- 66 -
Available functions in EasyTune 6 may differ by motherboard model. Grayed-out area(s) indicates that the item is
not configurable or the function is not supported.
Incorrectly doing overclock/overvoltage may result in damage to the hardware components such as CPU, chipset,
and memory and reduce the useful life of these components. Before you do the overclock/overvoltage, make sure
that you fully know each function of EasyTune 6, or system instability or other unexpected results may occur.
4-3 EasyTune 6
GIGABYTE's EasyTune 6 is a simple and easy-to-use interface that allows users to fine-tune their system
settings or do overclock/overvoltage in Windows environment. The user-friendly EasyTune 6 interface also
includes tabbed pages for CPU and memory information, letting users read their system-related information
without the need to install additional software.
The EasyTune 6 Interface
Tabs Information
Tab
Function
The
CPU
tab provides information on the installed CPU and motherboard.
The
Memory
tab provides information on the installed memory module(s). You can select memory
module on a specific slot to see its information.
The
Tuner
tab allows you to change system clock settings and voltages.
•
Easy mode
allows you to adjust the CPU FSB only.
•
Advanced mode
allows you to individually change system clock settings and voltages settings
using the sliders.
•
Easy Boost
is an easy-to-use auto-overclocking function
(Note)
. When activated, the system
automatically experiments all sorts of overclocking configurations till it hangs. After restart, the
system will operate with the optimum configurations tested to let the CPU reach the best
overclocking performance.
•
Save
allows you to save the current settings to a new profile (.txt file).
•
Load
allows you to load previous settings from a profile.
After making changes in
Easy mode
/
Advanced mode
, be sure to click
Set
for these changes to take
effect or click
Default
to restore to default values.
The
Graphics
tab allows you to change the core clock and memory clock for your ATI or NVIDIA
graphics card.
The
Smart
tab allows you to specify a C.I.A.2 level and a Smart Fan mode.
Smart Fan Advance Mode
allows the CPU fan speed to be changed linearly based on the CPU temperature thresholds you set.
The
HW Monitor
tab allows you to monitor hardware temperature, voltage and fan speed and set
temperature/fan speed alarm. You can choose the alert sound from the buzzer or use your own sound
file (.wav file).
(Note) Before enabling
Easy Boost
, right-click the EasyTune 6 icon
in the notification area. Select
Auto overclock
last tune on the next reboot
to allow the system to work with the optimum overclocking configuration after restart.
