BIOS Setup

- 32 -

2-1  Startup Screen

The following screens may appear when the computer boots.

A. The LOGO Screen (Default)

B. The POST Screen

Function Keys:
<TAB>: POST SCREEN

Press the <Tab> key to show the BIOS POST screen. To show the BIOS POST screen at system start-
up, refer to the instructions on the

Full Screen LOGO Show

 item on page 43.

<DEL>: BIOS SETUP\Q-FLASH

Press the <Delete> key to enter BIOS Setup or to access the Q-Flash utility in BIOS Setup.

<F9>: XPRESS RECOVERY2

If you have ever entered Xpress Recovery2 to back up hard drive data using the driver disk, the <F9>
key  can  be  used  for  subsequent  access  to  Xpress  Recovery2  during  the  POST.  For  more  information,
refer to Chapter 4, "Xpress Recovery2."

<F12>: BOOT MENU

Boot Menu allows you to set the first boot device without entering BIOS Setup. In Boot Menu, use the up
arrow key <

h

> or the down arrow key <

i

> to select the first boot device, then press <Enter> to accept.

To exit Boot Menu, press <Esc>. The system will directly boot from the device configured in Boot Menu.

Note: The setting in Boot Menu is effective for one time only. After system restart, the device boot order
will still be based on BIOS Setup settings. You can access Boot Menu again to change the first boot de-
vice setting as needed.

<END>: Q-FLASH

Press the <End> key to access the Q-Flash utility directly without having to enter BIOS Setup first.

Motherboard Model

 BIOS Version

Award Modular BIOS v6.00PG, An Energy Star Ally

Copyright (C) 1984-2009, Award Software, Inc.

AMD 770 BIOS for GA-MA770T-ES3 E1c

.

.

.

.

<DEL>: BIOS Setup  <F9>: XpressRecovery2  <F12>: Boot Menu  <End>: Qflash

10/27/2009-RX780-SB710-7A66AG0VC-00

Function Keys

Function Keys
