- 4 -
Table of Contents
Box Contents ................................................................................................................. 6
Optional Items ................................................................................................................. 6
GA-M68M-S2 Motherboard Layout ................................................................................ 7
Block Diagram ................................................................................................................ 8
Chapter 1 Hardware Installation .................................................................................... 9
1-1
Installation Precautions ..................................................................................... 9
1-2
Product Specifications .................................................................................... 10
1-3
Installing the CPU and CPU Cooler .............................................................. 12
1-3-1
Installing the CPU ................................................................................................ 12
1-3-2
Installing the CPU Cooler ................................................................................... 14
1-4
Installing the Memory ..................................................................................... 15
1-4-1
Dual Channel Memory Configuration ................................................................ 15
1-4-2
Installing a Memory ............................................................................................. 16
1-5
Installing an Expansion Card ......................................................................... 17
1-6
Back Panel Connectors ................................................................................. 18
1-7
Internal Connectors ........................................................................................ 20
Chapter 2 BIOS Setup ................................................................................................. 31
2-1
Startup Screen ................................................................................................ 32
2-2
The Main Menu .............................................................................................. 33
2-3
MB Intelligent Tweaker(M.I.T.) ....................................................................... 35
2-4
Standard CMOS Features ............................................................................. 38
2-5
Advanced BIOS Features .............................................................................. 40
2-6
Integrated Peripherals ..................................................................................... 42
2-7
Power Management Setup ............................................................................. 45
2-8
PnP/PCI Configurations ................................................................................. 47
2-9
PC Health Status ........................................................................................... 48
2-10 Load Fail-Safe Defaults ................................................................................... 50
2-11 Load Optimized Defaults ................................................................................. 50
2-12 Set Supervisor/User Password ..................................................................... 51
2-13 Save & Exit Setup ......................................................................................... 52
2-14 Exit Without Saving ....................................................................................... 52
