Hardware Installation

- 10 -

1-2

Product Specifications

C P U



Support for AM3/AM2+/AM2 processors:
AMD Phenom

™

 II processor/ AMD Phenom

™

 processor/

AMD Athlon

™

 II processor/ AMD Athlon

™

 processor/

AMD Sempron

™

 processor

(Go to GIGABYTE's website for the latest CPU support list.)

Hyper Transport Bus



2000 MT/s

Chipset



NVIDIA

®

 GeForce 7025/nForce 630a chipset

M e m o r y



2 x 1.8V DDR2 DIMM sockets supporting up to 8 GB of system memory

(Note 1)



Dual channel memory architecture



Support for DDR2 1066/800/667 MHz memory modules
(Go to GIGABYTE's website for the latest memory support list.)

Audio



Realtek ALC883 codec



High Definition Audio



2/4/5.1/7.1-channel

(Note 2)



Support for S/PDIF In/Out



Support for CD In

LAN



RTL8201CL chip (10/100 Mbit)

Expansion Slots



1 x PCI Express x16 slot, running at x16



1 x PCI Express x1 slot



2 x PCI slots

Storage Interface



NVIDIA

®

 GeForce 7025/nForce 630a chipset:

-

1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices

-

2 x SATA 3Gb/s connectors supporting up to 2 SATA 3Gb/s devices

-

Support for SATA RAID 0 and RAID 1



iTE IT8718 chip:
-

1 x floppy disk drive connector supporting up to 1 floppy disk drive

USB



Integrated in the NVIDIA

®

 GeForce 7025/nForce 630a chipset



Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets
connected to the internal USB headers)

Internal Connectors



1 x 24-pin ATX main power connector



1 x 4-pin ATX 12V power connector



1 x floppy disk drive connector



1 x IDE connector



2 x SATA 3Gb/s connectors



1 x CPU fan header



1 x system fan header



1 x front panel header



1 x front panel audio header



1 x surround/center audio header



1 x CD In connector



1 x S/PDIF In/Out header



2 x USB 2.0/1.1 headers
