17

Operation

1

2

3

4

5

6

1. Touch to quit the TV mode.
2. Touch to go to auto setting of channels.
3. Touch to go to manual setting menu.
4. Touch to switch channels.
5. Mute button; touch to switch sound on/off.
6. Touch to go to color setting menu.

Press MODE button on front panel or RC

to select TV mode or touch TV icon on main
menu screen to enter TV mode. Then touch the
center of the display to call the TV interface. To
select a menu page (Auto Setting or Manual
Setting) touch these items on the screen.
Touch the needed item on the screen to select
and adjust a parameter. Touch

 item on the

screen to return to last settings list.

AUTO PROGRAM
•  System: select TV system (SECAM/PAL/

NTSC).

•  Audio: select sound system (BG/I/DK).

For NTSC system, MN sound system can be
selected only.

•  Search: select to start automatical search

and storing of TV channels.

MANUAL PROGRAM
•  Storage: select the memory number of the

channel.

•  System: select TV system (SECAM/PAL/

NTSC). For NTSC system, MN sound system
can be selected only.

•  Audio: select sound system (BG/I/DK).
•  Channel: Select the number of the

channel.

•  Fine: perform fine tuning of picture quality.

•  Memory: select on (memorize the found

channel) or off (not memorize).

AV-IN mode

Connect an external audio/video signal

source to this unit. Select AV-IN mode in the
main menu or by pressing repeatedly MODE
button. In AV-IN mode touch   on the screen
to return to the main menu.

  Do not connect AV inputs on the rear

panel at the same time with the AV input on
the front panel. Interference of the signals can
damage the unit.

Disc/USB/SD/MMC operations

USB/SD/MMC notes

USB format supports 2.0. Capacity: up to 8

Gb.

For correct and satisfactory operation,

licensed SD/MMC memory cards of famous
brands should be used with this unit. Avoid
using memory cards of unknown brands.
Capacity: up to 8 Gb.

Insert/Eject disc

•  Insert a disc into the disc slot with label

side up. The disc will be automatically loaded
into the unit. The first file in the root folder will
be played.

•  Press   button to eject the disc from the

slot. If the disc is not removed from the slot
within several seconds, it will be automatically
loaded into the slot again. When the disc is
ejected and removed, the unit will automatically
switch to another mode.

Inserting a memory card/USB device

Insert an SD/MMC memory card into the

card slot. Open the USB slot cover on the front
panel and insert a USB into the USB slot. Then
the playing mode will be changed into SDHC
