Operation

Operation

the arrow icon in the right/left part of the screen
to switch between the 2 menu pages; or touch
the screen on any non-functional area, then
slide the page aside (rightwards/leftwards) to
select between the 2 menu pages.

  The Disc, USB and SDHC modes are

only available when a disc, USB or a memory
card is inserted into the unit.

Navigation (option)

•  Before switching the unit on, connect the

supplied GPS antenna to the GPS antenna input
on the rear panel.

•  Insert Navigation memory card into the

Memory card slot of the unit. The unit will
automatically switch to the SDHC mode. You
should select the map path (for more details,
see “System setup. General page“ item below).
This is required only for the first use of the
Navigation SD card. To enable navigation mode,
touch NAVIGATION button in the main menu or
press and hold MODE button on the panel.

•  For more details about operations with

navigation program, please read the instruction
manual to the navigation software. You can
download the quickstart guidance and full
instruction manual for the navigation program
from the web site of the navigation software
manufacturer.

AV in jack

AV jack is intended to receive audio and video

signals by connecting to external device.

Subwoofer

Connect a subwoofer to this unit using the

Subwoofer output of this unit. For subwoofer
operation an external amplifier is required.

System setup

When you select SETTING mode, the menu

will be displayed, in which you can touch any
item to select corresponding setting page:

1

2

3

4

1. Touch to return to the main menu.
2. Parameter list. Touch a parameter to select

it for adjustment.

3. Touch an icon to select corresponding

setting page.

4. Option/setting list. Touch to adjust the

corresponding parameter.

General page

•  Calibration: “Carefully press and hold

stylus on the center of the target. Repeat
as the target moves around the screen” is
displayed. Touch and hold the cross in each
position until it moves to a different position.
After repeating it 4 times, the calibration of the
screen is complete; touch the screen anywhere
to return to menu. The calibration procedure is
useful when some malfunction occurs with the
touch screen, and it needs adjustment.

•  Map Path: Select the path to the

navigation maps, when the navigation card is
inserted into the unit.

Sound page

•  Beep: Select ON (beep is heard at any

button pressing) or OFF (no beep).

•  Loud: Selecting loudness ON will

emphasize the low frequency output.

•  Subwoofer: set the subwoofer on or off.

Display page

•  Backlight: adjust the display brightness.
•  Backlight off: set the time after which the

screen will turn off automatically (if DIMMER is
