EN

20

Cleaning the brewing unit

The brewing unit must be cleaned at least once a month.

IMPORTANT!

The brewing unit (A5) must not be removed when the

appliance is on.

Do not use force to remove the brewing unit.

1. Make sure the machine is correctly turned off (see

“Turning the appliance off”).

2. Open the service door (fig. 16).
3. Remove the drip tray and waste coffee container (fig.

17);

4. Press the two red release buttons inwards and at the

same time pull the brewing unit outwards (fig. 31).

IMPORTANT!

Do not use washing up liquid to clean the brewing unit.

It would remove the lubricant applied to the inside of the

piston.

5. Soak the brewing unit in water for about 5 minutes, then

rinse.

6. After cleaning, replace the brewing unit (A5) by sliding it

onto the internal support and pin at the bottom, then push

the PUSH symbol fully in until it clicks into place.

Support

Pin

 N.B.:

If the brewing unit is difficult to insert, you must first adapt

it to the right dimensions by pressing it forcefully from the

bottom and top as shown in the figure.

7. Once inserted, make sure the two red buttons have

snapped out.

8. Replace the drip tray and waste coffee container.
9. Close the service door.

Cleaning the milk container

IMPORTANT!

Always clean the tubes inside the milk container (C) when

you prepare milk.

If there is still milk in the container, do not leave it out of

the refrigerator for longer than strictly necessary.

Clean the container each time you prepare milk as

described in Note 3 in the section “Making cappuccino”.

All components can be washed in a dishwasher, placing

them in the top basket of the dishwasher.

1. Turn the lid of the milk container clockwise then remove it.
2. Remove the milk spout and intake tube.
