Liebherr CN 3503 NoFrost - Инструкция по эксплуатации - Страница 9

u

To  access  temperature  adjustment:  press  setting  button,

freezer compartment

 Fig. 3 (6) once.

u

Press  the  setting  button,  freezer  compartment

  Fig.  3  (6)  the

number of times needed until the required temperature shines

in the LED display.

Note

u

Long pressing of the setting button sets a slightly colder value

within  a  small  temperature  range  (e.g.:  between -15  °C  and

-18 °C) but it is not visible in the display.

5.5.4 SuperFrost

With  this  function  you  can  freeze  fresh  food  quickly  through  to

the  core.  The  appliance  operates  with  maximum  refrigeration.

The noise of the refrigeration unit may be temporarily louder as

a result.
The maximum amount of fresh food which can be frozen in 24 h

is  indicated  on  the  type  plate  under  "freezing  capacity  ...  kg/

24h". This amount varies according to the model and climate rat-

ing.
Freezing with SuperFrost
You do not have to activate SuperFrost in the following cases:
- when placing frozen food in the freezer

- when freezing up to about 2 kg fresh food daily

u

Briefly press the SuperFrost button

 Fig. 3 (7).

w

The SuperFrost button shines.

w

The  freezer  temperature  drops,  the  appliance  operates  with

the maximum refrigerating capacity.

In case of a small amount of food to be frozen:

u

wait about 6 h.

u

Place the fresh food in the top drawers.

In case of the maximum amount of food to be frozen (see type

plate):

u

wait about 24 h.

u

Place food in the drawers.

w

SuperFrost is automatically deactivated after about 65 h.

w

The SuperFrost button is dark.

w

The appliance continues to operate in the energy-saving, nor-

mal mode.

5.5.5 Drawers

Note

The energy consumption increases and the cooling performance

decreases if there is insufficient ventilation.

For appliances with NoFrost:

u

Leave the bottom drawer in the appliance!

u

Always keep the air slits of the fan free at the rear wall!

u

To store frozen food directly on the shelves: pull the drawer

forwards and lift it out.

5.5.6 Shelves

u

To remove the shelf: lift up at the front and

pull out.

u

To put the shelf back: simply push in as far

as it will go.

5.5.7 VarioSpace

Apart  from  being  able  to  remove

the drawers, you can also remove

the  shelves,  creating  space  for

large  items  of  frozen  food.  Poul-

try,  meat,  large  pieces  of  game

and high bakery products can be

frozen in one piece and prepared.

u

The  maximum  load  of  frozen

food for an individual drawer or

shelf is 25 kg.

5.5.8 Information system

Fig. 11

*

(1) Ready-made meals, ice

cream

(4) Sausages, bread

(2) Pork, fish

(5) Game, mushrooms

(3) Fruit, vegetables

(6) Poultry, beef/veal

The figures indicate the storage time in months for several types

of frozen food in each case. Storage times given are guide times.

5.5.9 Freezer tray*

The freezer tray allows you to freeze berries, herbs, vegetables

and  other  small  items  of  food  without  them  sticking  together.

Items  being  frozen  will  largely  retain  their  shape,  and  it  will  be

easier to remove exactly the right quantity later on.
In addition, you can store the cold storage accumulators in the

freezer tray to save space.
Using the freezer tray*

u

Spread  the  items  out  loosely  on

the freezer tray.

u

Attach the freezer tray in one of the

upper drawers.

u

Allow  the  food  to  freeze  through

for 10 to 12 h.

u

Transfer the frozen food to freezer

bags or containers.

u

Store freezer bags or containers in a drawer.

u

To thaw the items, spead them out loosely again.

5.5.10 Cold storage accumulators*

The cold storage accumulators prevent the temperature from ris-

ing too quickly in case of power failure.
Using cold storage accumulators*

u

Place the cold storage accumula-

tors  in  the  freezer  tray  to  save

space.

u

Place the frozen cold storage ac-

cumulators  straight  on  top  of  the

frozen food in the top drawer.

w

This way the frozen food will keep

cool longest in case of power fail-

ure.

Control

9
