w

The fan is active. It switches on automatically when the com-

pressor runs.

To switch off the fan

u

Briefly press the fan button

 Fig. 3 (2).

w

The fan button goes out.

w

The fan is switched off.

5.4.4 Relocating the shelves

The shelves have stops preventing them from being unintention-

ally pulled out.

u

Lift the shelf and draw it out forwards.

u

Insert shelf with the raised edge pointing upwards at the back.

w

The food does not freeze onto the rear wall.

5.4.5 Using the sectioned shelf

Fig. 10

u

The glass shelf with stop face (2) has to be at the back.

5.4.6 Moving the storage rack*

u

Remove  storage  rack  according  to  il-

lustration.

The boxes can be removed and placed on the table as a single

unit.
Only one box or both boxes can be used. If particularly tall bottles

are to be stored, attach only the wide box above the bottle rack.
Three small boxes are available through the customer service as

optional equipment instead of one wide and one small box.

u

Re-positioning the boxes: Lift them for

removal  and  re-position  them  as  re-

quired.

u

To  detach  lid:  Open  90°  and  raise  to

disengage.

Always  remove  the  butter  and  cheese

compartment together with the lid.

u

To remove lid: Press one side part of

the  butter  and  cheese  compartment

outwards until the lid pin is clear and

then remove the lid sideways.

5.4.7 Removing the bottle holder*

u

Remove the bottle holder according to

the illustration.

u

Always take hold of the bottle holder on

the plastic part.

5.5 Freezer compartment

You can store frozen food, make ice cubes and freeze fresh food

in the freezer compartment.

5.5.1 Freezing food

The maximum weight of fresh food which can be frozen within 24

h  is  indicated  on  the  type  plate  under  "freezing  capacity  ...  kg/

24h".
The  maximum  load  for  an  individual  drawer  and  the  plate  is

25 kg frozen food.

CAUTION

Risk of injury due to broken glass!

Bottles and cans containing drinks may burst when being frozen.

This applies particularly to sparkling drinks.

u

Do not freeze bottles and cans containing drinks!

In order that the food is rapidly frozen through to the core, do not

exceed the following quantities per pack:
- Fruit, vegetables up to 1 kg

- Meat up to 2.5 kg

u

Pack  the  food  in  portions  in  freezer  bags,  reusable  plastic,

metal or aluminium containers.

5.5.2 Thawing food

- in the refrigerator compartment

- at room temperature

- in a microwave oven

- in a conventional or fan oven

u

Food  once  thawed  should  be  re-frozen  only  in  exceptional

cases.

5.5.3 Setting the temperature

Temperature setting to be recommended: -18 °C
The  temperature  can  be  changed  continuously.  Once  the

-32 °C setting is reached, it starts again with -15 °C.

Control
