Liebherr CN 3503 NoFrost - Инструкция по эксплуатации - Страница 11

CAUTION

Risk of injury and damage as a result of hot steam!

Hot steam may damage the surfaces and cause burns.

u

Do not use any steam cleaners!

ATTENTION

Incorrect cleaning damages the appliance!

u

Do not use cleaning agents in concentrated form.

u

Do not use any scouring or abrasive sponges or steel wool.

u

Do  not  use  any  cleaning  agents  containing  sand,  chloride,

chemicals or acid.

u

Do not use chemical solvents.

u

Do not damage or remove the type plate on the inside of the

appliance. It is important for the customer service.

u

Do not pull off, bend or damage cables or other components.

u

Do  not  allow  any  cleaning  water  to  enter  the  drain  channel,

ventilation grille or electrical parts.

u

Empty the appliance.

u

Pull out the power plug.

- Use soft cleaning cloths and a multi-purpose clean-

ing agent with neutral pH value.

- Only use food compatible cleaning and care agents

on the inside of the appliance.

Outside surfaces and interior:

u

Regularly clean ventilation grilles.

w

Dust deposits increase energy consumption.

u

Clean the plastic surfaces, outside and inside, by hand using

lukewarm water and a little washing-up liquid.

Clean  stainless  steel  surfaces  with  a  standard  stainless  steel

cleaning  agent.  Darker  areas  at  the  beginning  and  quite  an  in-

tensive colour of the stainless steel surface are normal.*

u

Do not apply cleaners to glass or plastic surfaces so as not to

scratch them.*

u

To  clean  stainless  steel  surfaces:  evenly  apply  an  agent  for

care of stainless steel, wiping in the direction of the grain.*

u

To  clean  the  drain  opening:  remove

any  deposits  with  a  fine  instrument,

e.g. a cotton bud.

Items of equipment:

u

Clean items of equipment by hand with lukewarm water and

a little washing-up liquid.

u

For cleaning, remove the support rails for the half-sized glass

shelves.

u

To  dismantle  the  shelves:  remove

the trims and side parts.

u

To  dismantle  the  storage  rack:  re-

move  the  protective  film  from  the

decorative trims.*

*

u

Lift out the boxes and lift the covers

for removal.*

*

After cleaning:

u

Wipe dry the appliance and items of equipment.

u

Connect the appliance and switch it on again.

u

Activate SuperFrost . (see section on SuperFrost)

When the temperature is sufficiently cold:

u

Put the food back inside.

6.3 Cleaning the IceMaker*

Fig. 13

The IceMaker has to be switched on.

u

Pull out the drawer and remove the ice cubes.

u

Clean the drawer with warm water and mild washing-up liquid.

u

When the drawer is pulled out, hold down the On/Off button

(about 10 seconds).

w

After about 1 s the LED goes out, the IceMaker is switched off.

w

After about 10 s the LED flashes for about 60 s.

u

Slide in the drawer while the LED is flashing.

w

The ice-cube tray of the IceMaker turns to a skew position.

u

Remove the drawer.

u

Clean the ice cube tray with warm water. If necessary, use mild

washing-up liquid. Then rinse.

Switch the IceMaker on again.

u

Press the ON/OFF button until the LED shines, then slide in

the drawer.

w

The IceMaker starts producing ice cubes.

If washing-up liquid was used:

u

throw away the first three loads of ice cubes to get rid of any

remaining washing-up liquid.

6.4 Changing the interior light with bulb

Bulb data

max. 25 W

Fitting: E14

Type of current and voltage must conform with the details on

the type plate

u

Switch off the appliance.

u

Pull  out  the  power  plug  or

switch off the fuse.

u

Take  holder  of  the  cover

Fig.  14  (1)  at  the  front  and

unhook it at the back.

u

Change

the

bulb

Fig. 14 (2).

u

Put  the  cover

  Fig.  14  (1)

back in place.

Fig. 14

6.5 Customer service

First  check  whether  you  can  correct  the  fault  yourself  by  refer-

ence to the list in the section on troubleshooting. If this is not the

case, please contact the customer service whose address is giv-

en in the enclosed customer service list.

WARNING

Risk of injury if repair work is not carried out professionally!

u

Have  any  repairs  to  and  intervention  in  the  appliance  and

mains power cable, which are not expressly mentioned in the

section on maintenance, carried out by the customer service

only.

Maintenance

11
