INFO

CONTRAST

CONTRAST
INFO

LANGUAGE

Language selection

3.2 Operating the display

Fig. 3

(1) Refrigerator compart-

ment temperature

display

(5) Left button

(2) Freezer compartment

temperature display

(6) Up button

(3) OK button

(7) Down button

(4) Right button

You can operate all the functions of the appliance via the display:

-

To activate the main menu: Press any button.

-

To move the cursor up: Press Up button

 Fig. 3 (6).

-

To move the cursor down: Press Down button

 Fig. 3 (7).

-

To move the cursor to the left: Press left button

 Fig. 3 (5).

-

To  move  the  cursor  to  the  right:  Press  right  button

Fig. 3 (4).

-

Lengthy info text is on several pages in the display:

•

To page forwards: Press right button

 Fig. 3 (4).

•

To page back: Press left button

 Fig. 3 (5).

-

To confirm selection: Press OK button

 Fig. 3 (3).

-

To quit menu: Press left button

 Fig. 3 (5).

3.3 Temperature display

The following are displayed in normal operation:

-

the warmest freezing temperature

-

below the freezing temperature: the pre-set temperature in the

freezer compartment

-

the average cooling temperature

-

above the cooling temperature: the pre-set temperature in the

refrigerator compartment

The freezer compartment temperature display flashes:

-

the temperature setting is being changed

-

after switch-on the temperature is not yet cold enough

-

the temperature has risen several degrees

Dashes flash in the display:

-

the freezer temperature is above 0 °C.

The following displays indicate malfunction. Possible causes and

corrective action  (see Malfunction).

-

F0 to F9

-

FE

-

POWER FAILURE

-

CHECK WATER SUPPLY

4 Putting into operation

4.1 Changing over the door hinges

You can change over the door hinges if necessary.
Ensure that the following tools are to hand:

q

Torx 25

q

Torx 15

q

Screwdriver

q

Cordless screwdriver, if necessary

q

Second person for fitting work, if needed

4.1.1 Detaching the upper soft stop mechanism

For appliances with soft stop mechanism start with this point.
For  appliances  without  soft  stop  mechanism  start  with:

(see 4.1.2) .

Fig. 4

u

Open the upper door.

NOTICE

Risk of damage!

If the door seal is damaged, the door may fail to close properly

and the cooling will be inadequate.

u

Do not damage the door seal with the screwdriver!

u

Disengage  and  remove  the  faceplate

  Fig.  4  (1)  using  a  flat-

blade screwdriver.

w

The faceplate is attached over the soft stop bracket.

Putting into operation
