u

Activate  the  FREEZER  ->  ICEMAKER  ->  WATER  INTAKE

menu items one after the other.

u

To  decrease  the  water  intake  time:  Press  Up  button

Fig. 34 (6).

-or-

u

To  increase  the  water  intake  time:  Press  Down  button

Fig. 34 (7).

6 Maintenance

6.1 Defrosting with NoFrost

The NoFrost system automatically defrosts the appliance.
Refrigerator compartment:
The defrost water evaporates due to the compressor heat.

u

Regularly  clean  the  drain  opening  to  allow  the  water  to  flow

away  (see 6.2) .

Freezer compartment:
The  moisture  condenses  on  the  evaporator,  is  periodically

defrosted and evaporates.

u

The appliance does not have to be manually defrosted.

6.2 Cleaning the appliance

Before cleaning:

CAUTION

Risk of injury and damage as a result of hot steam!

Hot steam may damage the surfaces and cause burns.

u

Do not use any steam cleaners!

NOTICE

Incorrect cleaning damages the appliance!

u

Do not use cleaning agents in concentrated form.

u

Do not use any scouring or abrasive sponges or steel wool.

u

Do  not  use  any  cleaning  agents  containing  sand,  chloride,

chemicals or acid.

u

Do not use chemical solvents.

u

Do not damage or remove the type plate on the inside of the

appliance. It is important for the customer service.

u

Do not pull off, bend or damage cables or other components.

u

Do  not  allow  any  cleaning  water  to  enter  the  drain  channel,

ventilation grille or electrical parts.

u

Empty the appliance.

u

Pull out the plug.

- Use  soft  cleaning  cloths  and  a  multi-purpose

cleaning agent with neutral pH value.

- Only use food compatible cleaning and care agents

on the inside of the appliance.

u

Regularly clean ventilation grilles.

w

Dust deposits increase energy consumption.

Outside surfaces and interior:

u

Clean the plastic surfaces, outside and inside, by hand using

lukewarm water and a little washing-up liquid.

NOTICE

The stainless steel doors are provided with a high-quality surface

coating  and  must  not  be  treated  using  the  accompanying  care

product.

Otherwise the surface coating will be affected.

u

Wipe the coated door surfaces using a soft, clean cloth only.

In case of stubborn dirt, use a little water or a neutral cleaning

agent. A microfibre cloth can be optionally used.

u

If the stainless steel side walls are dirty, clean them using

a commercially available stainless steel cleaning agent. Then

evenly apply the accompanying stainless steel care product,

making strokes in the direction of the grain.

u

Wipe side walls with a paint finish using a soft, clean cloth

only.  In  case  of  stubborn  dirt,  use  a  little  water  or  a  neutral

cleaning agent. A microfibre cloth can be optionally used.

u

To  clean  the  drain  opening:  remove

any  deposits  with  a  fine  instrument,

e.g. a cotton bud.

Items of equipment:

u

Clean items of equipment by hand with lukewarm water and

a little washing-up liquid.

u

For cleaning, remove the support rails for the half-sized glass

shelves.

u

To dismantle the shelves: remove the

trims and side parts.

u

To  dismantle  the  storage  rack:

remove  the  protective  film  from  the

decorative trims.

After cleaning:

u

Wipe dry the appliance and items of equipment.

u

Connect the appliance and switch it on again.

u

Switch on SuperFrost (see 5.10.4) .

6.3 Cleaning the IceMaker

The ice cube container has to be empty and slid into place.

u

Activate the MAIN MENU.

u

Activate  the  FREEZER  ->  ICEMAKER  ->  TWISTCLEAN

menu items one after the other.

u

Set the cursor to INFO.

u

Press OK button

 Fig. 3 (3).

w

The info text in the display describes the use of the TwistClean

function.

u

Press the left button

 Fig. 3 (5) until START and INFO are indi-

cated in the display.

u

Set the cursor to START.

u

Press OK button

 Fig. 3 (3).

w

TwistClean appears in the display at the bottom, the IceMaker

moves into cleaning position.

When TWISTCLEAN goes out in the display:

u

Remove ice cube container and clean with warm water and a

little washing-up liquid.

u

Slide ice cube container back into place.

Either leave the IceMaker switched off in this position or switch

it on again via MAIN MENU -> FREEZER -> ICEMAKER -> ON.

6.4 Changing the interior light with bulb*

Bulb data

Maintenance
