- 53 -

CHANGING THE DIRECTION

OF THE DOOR OPENING

Changing the direction of the door opening (Fig. 20)

1.   Before reversing the door opening direction, unplug the appliance

and remove all food.

2.   Using a flat screwdriver pry and remove hinge caps.

3.   Using a Phillips screwdriver remove the door upper hinge while

holding the door (Fig. 20.1).

4.   Using a Phillips screwdriver remove the middle hinge while holding

the upper door*

5.   Set the door aside in a safe place.

6.   Tilt the appliance (up to 40 degrees) so as to have sufficient access

to the lower hinge (Fig. 20.2).

7.   Using a Phillips screwdriver remove lower door hinge

8.   Attach the lower hinge on the other side (Fig. 20.3).

9.   Position the door assembly in such a way so that pin of the lower

hinge is aligned with the appropriate hole of the lower door brack-

et.

10.  Attach the middle hinge on the other side of the appliance so that

the lower pin of the middle hinge is aligned with the appropriate

hole of the upper door bracket. Position the second door assembly

so that the upper pin of the middle hinge is aligned with the appro-

priate hole of the lower door bracket.*

11.  Attach the upper hinge so that the hinge pin is aligned with the

appropriate hole of the upper door bracket.* (Fig. 20.4).

12.  Check that doors are properly aligned with the appliance body.

13.  Replace the hinge caps.

14.  Switch on the appliance as described in the relevant section of its

operating instructions.

* This action applies to appliances with both refrigeration and freezer

chambers.
